- Page 1 CAME.COM/UK MTMA/connect Covering MTM / MTMVR / VRW / VRM Surface/Flush Mount 4G Audio Intercom quick setup reference guide KM4G080C for full instructions please refer to the installation manual...
- Page 2 MTM Call Panel MTM VR Call Panel VRW Call Panel VRM Call Panel Intercom Intercom Intercom Intercom VAS/101 antenna mounting box rain hood CAME Key Power Supply With cable and For flush mount or surface mount WiFi Interface mounting bracket intercoms...
- Page 3 general precautions • Read the instructions carefully before beginning the installation and carry out the actions as specified by the manufacturer. • The installation, programming, commissioning and maintenance of the product must only be carried out by qualified technicians, properly trained in compliance with the regulations in force, including health and safety measures and the disposal of packaging.
- Page 4 TITLE dimensions Size 1 Size 2 Size 3 Size 4 Type Mounting W x H x D (mm) 135 x 138 x 64 135 x 228 x 64 135 x 318 x 64 135 x 408 x 64 Surface 130 x 136 x 62 130 x 226 x 62 130 x 316 x 62 130 x 406 x 62...
- Page 5 pre-commissioning inserting the micro sim card 1. Please ensure that the module is disconnected from the mains power. 2. Insert the Micro SIM card into the slot as shown in the diagram Please note: the Micro SIM is not included with the kit and will need to be purchased separately.
- Page 6 installation: recessed Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the recess mounting box • Slide the electronic modules into place • Screw the outer frame into place over the modules, •...
- Page 7 TITLE installation: surface Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the rain hood • Slide the electronic modules into place • Screw the outer frame into place over the modules, •...
- Page 8 TITLE installation: recessed Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the recess mounting box • Slide the electronic modules into place • Snap the pre-configured front panels securely into place over the modules, using the clips circled •...
- Page 9 TITLE installation: surface Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the recess mounting box • Slide the electronic modules into place • Snap the pre-configured front panels securely into place over the modules, using the clips circled •...
- Page 10 TITLE installation: recessed Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the recess mounting box • Slide the electronic module(s) into place • Connect the ribbon cable from the button to the •...
- Page 11 TITLE installation: surface Items illustrated may differ from kit contents. All modules & frames are fitted in the same way. • Fit the aluminium module-housing profile into the recess mounting box • Slide the electronic module(s) into place • Connect the ribbon cable from the button to the •...
- Page 12 MTMA/CONNECT – Audio Module Speaker LED warning light: conversation in progress (yellow) LED warning light: door open (green) Connector for CAME KEY Microphone Reset button (restart the device) Network diagnostics LED Call buttons LED warning light: user busy (blue)
- Page 13 MTMA/CONNECT – Audio Module Terminal board for electrical connections Power supply t c e c i r t c e c i r t c e n o i . x a Door release button (NO) e l b...
- Page 14 MTMA/CONNECT CONTROL BOARD VAS/101 12v DC Push to Open Strike Cable/length Switch 25m (2x1mm ) or 60m (2x2.5mm...
- Page 15 MTMA/CONNECT CONTROL BOARD GATE OPERATOR CONTROL BOARD 12v DC Push to Open Strike A B GND 11 10 Switch...
- Page 16 Should adding the gateway the email not arrive, please to your technician account check your junk folder. 3.1 Select “CAME Connect 3.2 Select “Managing 3.3 You can either select an 3.4 Select “Add Gateway”. connection” in order to Installations”...
- Page 17 (shown here on iPhone), and password, enter 01234567. to access the Internet. select the WiFi connections. Wait for the LED on the CAME In this example, we have used an BLUE. Key to turn EE 4G SIM card, and for EE the APN is simply ‘everywhere’.
- Page 18 This new button manages the CAME KEY, as it is no longer Door Entry functions, which we required. will look at next - otherwise it acts like a normal CAMEconnect gateway, and devices can be added to it in the normal manner.
- Page 19 TITLE commissioning via app 4.9 Now let’s add the right 4.10 If no call button 4.7 Or you can select NO 4.8 When happy with the destinations (units) have been hand call button. On the buttons – or press the button configuration, press BACK programmed previously, you image of the base module on...
- Page 20 commissioning via app Main House 4.15 We can now associate 4.16 Now select the desination 4.17 If there are no contacts 4.18 A list of available associated yet with the contacts is shown, you can the Contacts to the Call i.e Main House Buttons.
- Page 21 TITLE commissioning via app configuring the crp gateway 5.1 From the Device menu 5.2 A menu will appear (see 5.3 Select the Operator 5.4 Your selected operator within the site, press the three right) with a series of options. type (in the example we will now appear below the dots icon to the right of the As per normal when adding...
- Page 22 TITLE commissioning via app OPTIONAL: If you choose to transfer site ownership to your customer, you will lose the ability to remotely manage this system, unless your customer raises a support transfer to request giving you permission to access the system. customer Transferring site ownsership will allow your customer to make changes to the system.
- Page 23 settings The APN settings listed below are correct as at March 2024, but may be subject to change from the Mobile Network Operator. Should the below settings not work for your sim, please contact the Mobile Network Provider who will be able to confirm the correct APN to use.
- Page 24 DTMF settings The system has preset DTMF tone settings. During a call pressing a key combination will carry out a specific function. For example to increase the volume on the speaker Key 1#. There are 8 of these that are set by default. 4 of which cannot be changed. The other 4 can be modified from their default settings if required.
- Page 25 DTMF settings changing dtmf shortcut keys 10.1 From the Main Menu 10.2 To change the preset 10.3 Select Modify. 10.4 Replace the code with Press “DTMF tones”. DTMF key combination press your desired key combination the 3 dots as pictured above. Note: key combinations must be a minimum of 2 characters.
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
