Summary of Contents for CAME MTMA/CONNECT
- Page 1 FA02097-EN 4G/LTE audio module for modular entry panel CAME S.p.A. Via Martiri della Libertà, 15 MTMA/CONNECT 31030 Dosson di Casier Treviso – Italy Tel. (+39) 0422 4940 Fax (+39) 0422 4941 info@came.com - www. INSTALLATION AND CONFIGURATION MANUAL came.com English...
-
Page 2: General Precautions
It supports configuration and remote management via the CONNECT SetUp app and CAME Connect portal. A CAME Key is required for the initial installation. Connect and control up to 2 CAME operators and use its gateway function. It supports sending commands to entry panels and operators via DTMF tones and the Automation... -
Page 3: Description Of Parts
Description of parts Speaker CAME KEY adapter (88040-0055) LED warning light: conversation in progress (yellow) Antenna plug LED warning light: door open (green) Micro SIM card Connector for CAME KEY Slot for Micro-SIM-CARD (Push-Push) Microphone Hearing-impaired module housing Reset button (restart the device) -
Page 4: Technical Data
(**) The average product life specified should be understood purely as an indicative estimate. It applies to normal usage conditions and where the product has been installed and maintained in compliance with the instructions provided in the CAME technical manual. The average product life is also affected, including significantly, by other variables such as, but not limited to, climatic and environmental conditions. -
Page 5: Installation And Connections
INSTALLATION AND CONNECTIONS Inserting the micro SIM card Before performing the steps below, make sure that the module is disconnected from the mains power. Insert the micro SIM card in the relevant slot. Attaching the antenna Connect the antenna to the relevant connector on the module. Use the extension cable for remote control of the antenna. To improve the antenna reception, use a metal support as shown. - Page 6 − CONTROL BOARD Power supply and connection to a single CAME operator with CRP protocol If communication with the operator is unstable, it may be necessary to connect the line resistor to the RSE device (jumper set to on). MTMA/CONNECT −...
- Page 7 Connection with power supply from CAME operator and with two CRP nodes The example shows the maximum system limit. MTMA/CONNECT − − CONTROL BOARD CONTROL BOARD Cable length Section VCM/1D UTP CAT5 2x2.5mm² La+Lb ≤ 1000 m ≤ 25 m...
-
Page 8: Configuring The System
User - If the installer/admin has shared the system, the user can view the installation configuration (operators and additional devices) and control any operators. Creating a new system Log in as an installer to configure the system for the first time. For the first system configuration, select the connection type via CAME Connect (remote connection). Create a new installation under [Installation management]. - Page 9 » If you select “add with QR code”, you will be asked to scan the QR code on the MTMA/CONNECT label under [KEYCODE]. » If you select “manual add”, you will need to enter the keycode on the MTMA/...
-
Page 10: Wifi Configuration
MTMA/CONNECT connector using the relevant adapter. The red LED on the CAME KEY will light up. If the blue LED on the CAME KEY flashes, a device is connected to the network. Wait for it to disconnect before continuing with configuration. - Page 11 If the micro SIM card is later replaced, the operator APN and PIN will need to be set again. Use the CAME KEY to perform this new network configuration. If the APN is incorrect, the device cannot connect to the internet and voice calls cannot be guaranteed.
- Page 12 Configuring APN via SMS This option is only available for devices with firmware version V1.05.000 onwards. The SIM card (not included) must be enabled for sending and receiving SMSs and the PIN code must not be active. Check the availability and cost of the required services with your mobile telephone provider. Data consumption depends on the number and type of devices associated with the module, and how they are used with the CAMEConnect system.
- Page 13 Installations list The gateway is shown in the [Device list]. View the [Signal level] under [Information] by clicking on [Read level]. Press the symbol to perform the following operations. » [Add automation] is used to add a new operator associated with the registered device.
-
Page 14: Managing The System
Managing the system Creating users (Address book) You can now manage the system you have created. In the [Address book] section, add single entry-panel users and their phone numbers. A specific [Dial-to-open action] can be assigned to each contact. With the [Dial-to-open action], every time a user calls the entry panel phone number, the indicated actions are performed. -
Page 15: Managing Units
Managing units Under [Unit management], create the units to be associated with the entry-panel call buttons. The units are made up of one or more contacts in the [Address book]. When a call button is pressed, the entry panel calls the first number that was added to the unit. - Page 16 Managing modules and associating call buttons Under [Module management]: 1 Add secondary modules to MTMA/CONNECT by pressing [Add module] 2 Modify the information for the modules in the system by pressing 3 Modify the settings for the modules in the system by pressing...
-
Page 17: Call Buttons
Call buttons symbol is used to edit the image of the main module front. Press the call buttons to assign a unit from the list to each one. If the unit is not in symbol is used for updating the module firmware. See paragraph [Firmware the list, create it by pressing [New]. - Page 18 Call forwarding to voicemail function This function allows the MTMA/CONNECT to distinguish between the user answering and the voicemail activating. When the voicemail is activated for the number called, the user is considered to be unavailable and the call is forwarded to the next recipient in the unit list.
-
Page 19: Module Settings
Managing secondary module - MTMRFID Module settings Manage keycards From this screen you can set the requirements for accepting MIFARE keycards. Press the symbol on the RFID module to insert or remove keycards and tags. By enabling [Only protected MIFARE accepted], the RFID device recognises protected Press [Add keycard] to choose the acquisition mode. - Page 20 » [Local acquisition] is used to store information by resting the keycard on the MTMRFID module reader. The module must be connected during acquisition. » [Add with QR code] is used to store the information by scanning the QR code on the keycard (where present).
- Page 21 Choose [Welcome messages] to set a message that will be shown as text on the display. Custom language Choose [Custom language] to set text strings that will be shown on the display. Set [Custom] under [Language] in the MTMA/CONNECT module settings.
-
Page 22: Firmware Updates
Press to update the module firmware. The system automatically selects the latest firmware version available in the cloud. If there are any connectivity problems, update the firmware using the CAME KEY by selecting the desired FW version. The LTE module firmware can also be updated from the main module menu. -
Page 23: Final Operations
FINAL OPERATIONS Once configuration is complete, program the system to activate the settings chosen on the devices. When the symbol is shown on the [Program system] button, this means changes have been made from the app which still need to be sent to the device. Press [Program system] to start the programming procedure. - Page 24 USER GUIDE LIST OF DTMF TONES DTMF tones are adjustments and commands sent from your smartphone keypad during a conversation with MTMA/CONNECT. There is a numerical combination for each command followed by the # key. Speaker volume + Adjust the MTMA/CONNECT speaker volume...
