7 - FURTHER DETAILS - ADVANCED MENU
The ADVANCED MENU allows the system to be further customi-
sed by modifying parameters not accessible from the basic menu
To access the ADVANCED menu, press the MENU key and hold it
PARAMETERS
Electric brake
EL.F.
0 = off
1
1 = on
Use of PHOTO1 when starting from closed
SP.h.
0 = PHOTO1 is checked
2
1 = The gate starts even with PHOTO1 excited
Use of PHOTO2
Ph.2.
0 = Enabled during both opening and closing AP/CH
3
1 =Only enabled during opening AP
Photo-device test
0 = off
tP.h.
1 = PHOTO1 on
4
2 = PHOTO2 on
3 = PHOTO1 and PHOTO2 on
Sensitive edge type
Ed.m.
5 0 = contact (NC)
1 = resistive (8k2)
Sensitive edge tripping mode
0= only tripped during closure with direction reversal
iE.D.
6
1 = stops the automation (during both opening and
closure) and retreats from the obstacle
Edge test
tE.D.
7 0 = off
1 = on
LP.o.
8 Partial opening
TP.C.
Time for automatic closure from partial opening (0=off)
9
Flashing light output setup
FP.r.
0 = Steady
10
1 = Flashing
tP.r.
Pre-flashing time (0 = off)
11
Courtesy light setup
0 = On at end of operation for time TCY
1 = On if gate not closed + duration of TCY
FC.Y.
12
2 = On if courtesy light timer (TCY) time not out
3 = Gate open light on/off
4 = Gate open light proportional flashing
tC.Y.
13 Courtesy light on time
Hold-to-run
de.a.
0 = off
14
1 = on
Service interval cycle threshold. Once the set
threshold is reached, the light flashes
se.r.
at high speed in all subsequent cycles (only if FPR is
15
on).
(0 = off)
Enabling of continuous flashing indicating
.)service required (only active with gate closed
se.f.
16
off = 0
on = 1
de.f.
Restoring the default values
17
To set the default values: 1) access the advanced programming
function; 2) select the "dEf" parameter"; 3) activate the modification
mode ("0" on display"); 4) accept the modification (press "MENU"
down for 5 seconds
To modify ADVANCED MENU parameters, proceed as described
for the BASIC MENU
DESCRIPTION
and hold it down). A countdown should now appear: d80,d79...,d01
down to "
DEFAULT
0
1
0
0
0
0
0
30
20
1
0
0
0
0
0
0
don ". Release the key when finished.
MIN MAX UNIT
x 0.01s
0 100
(step of 5)
0 1
0 1
0 3
0 1
0 1
0 1
0 100 % (step of 1)
0 900 s
0 1
0 10 s
0 4
s
0 900
(step of 10s)
0 1
x 1000
0 100
cycles
0 1
