2 - INTRODUCING THE PRODUCT
2.1 - Product description
Irreversibile electromechanical gearmotor for sliding gates weighing up to 2000 kg at 230 Vac.
2.2 - Set panel and and technical specifications
TECHNICAL DATA
Speed*
Torque
Duty cycle
Control unit
Voltage
Frequency
Motor consumption
Absorbed power
Capacitor
Thermoprotection
Protection degree
Dimensions (L-P-H)
Weight
Working temperature
Max gate weight
* Variable data according to gate weight
LIMIT USE: The limit use refer to the recommended weight (about
2/3 of maximum allowed weight). Use with maximum allowed wei-
ght could reduce the above performance specifications in tecnhical
data. The working cycle, operating times and number of consecutive
cycles are merely approximate. These have been statistically de-
termined in average conditions of use and are not certain for each
3 - PRELIMINARY CHECKS
Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
mum permissible operating limits specified in paragraph 2.2
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of the product is not subject to flo-
oding
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
SC202MK
cm/s
Nm 110
% 50/70
CT102B
Vac 230
Hz 50 - 60
A
W 920
µF
°C 160
IP
mm 360 - 270 - 390
kg
°C -20 +55
kg 2000
single case. They refer to the period when the product operates wi-
thout the need for special maintenance.- Each automatic entrance
features variable factors such as: friction, balancing and environ-
mental conditions that can substantially change both the duration
and operating quality of the automatic entrance or part of its compo-
nents (including automatic system). It is up to the installer to adopt
adequate safety coefficients for each single installation.
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
differential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
17
4
25
44
24
