5 - CONTROL BOARD
5.1 - Description of the control unit
The CT102 control unit is the most modern, efficient system for the
control of Key Automation motors for the electric opening and closure
of sliding gates and up-and-over doors.
All other, improper, use of the control unit is forbidden. The CT102 has
20
FUSE 2
L1
1
COM
L2
2
COND
21
5.2 - Description of the connections
1- Motor power supply connections
2- Capacitor connector
3- 230 Vac power supply connections to flashing and
courtesy lights
4- 24 Vdc power supply connection to controls and safety devices
5- RED EDGE-PH2-PH1-STOP safety warning LEDs
6- GREEN OPEN-CLOSE-PAR-SBS command indicator LEDs
7- Radio PCB connector with RX4Y connection (4 channels)
8- Antenna connector
9- LCD display
10- Limit switch connector
5.3 - List of cables required
The cables required for connection of the various devices in a stan-
dard system are listed in the cables list table.
ELECTRIC CABLE TECHNICAL SPECIFICATIONS:
Connection
Control unit power supply line
Flashing light, courtesy light
Antenna
Transmitter photocells
Receiver photocells
Sensitive edge
Key-switch
* If the power cable is longer than 30 m, a cable with a larger cross-section is required (3G2.5 mm
vicinity of the automation.
** Two cables of 2 x 0.5 mm
10
19
11
12
18 17
3
can be used as an alternative
2
a display allowing easy programming and constant monitoring of the
input status; the menu structure also allows easy setting of working
times and operating modes.
9
14
MENU
UP DOWN
13
15
SBS
5 6
4
11- Limit switch indicator LED LS1
12- Limit switch indicator LED LS2
13- UP + button
14- MENU button
15- DOWN - button
16- STEP BY STEP SBS button
17- Safety device dip switch
18- Transformer primary
19- Transformer secondary
20- F2- 800 mA rapid fuse protecting the accessories
21- F1- 6.3 A rapid fuse protecting the line
The cables used must be suitable for the type of installation; for
example, an H03VV-F type cable is recommended for indoor appli-
cations, while H07RN-F is suitable for outdoor applications.
cable
1 x cable 2G1,5 mm
1 x cable 4 x 0,5 mm
1 x cable type RG58
1 x cable 2 x 0,5 mm
1 x cable 4 x 0,5 mm
1 x cable 2 x 0,5 mm
1 x cable 4 x 0,5 mm
SHIELD
ANT
8
16
7
RECEIVER RX4Y
OUTPUT 1 = STEP BY STEP
OUTPUT 2 = PARTIAL
OUTPUT 3 = OPEN
OUTPUT 4 = LIGHTS ON/OFF
maximum allowable limit
20 m *
2
** 20 m
2
20 m (advised < 5 m)
20 m
2
20 m
2
20 m
2
20 m
2
) and safety earthing is necessary in the
2
J3
