PARAMETERS
1 TCL
ttr
2
trq
3
4 SS
SbS
5
blt
6
7 SST
8 LSI
6.5 Connecting the radio receiver
Connect the radio receiver, removing the plastic cover and taking
care to position it as shown in the diagram in point 2.1.
For programming, follow the receiver instructions, remembering that
DESCRIPTION
Automatic reclosure time (0 = off)
Reclosing time after transit (0 = off)
Motor force (peak torque)
Deceleration mode
0 = 1/3 deceleration
1 = 2/3 deceleration
SBS configuration:
0 = Normal (AP-ST-CH-ST-AP-ST...)
1 = Alternate STOP (AP-ST-CH-AP-ST-CH...)
2 = Alternate (AP-CH-AP-CH...)
3 = Apartment block – timer
4 = Apartment block with immediate reclosure
Post blackout procedure
0 = no action, remains stationery
1 = Closure
Soft start
0 = off
1 = on
Deceleration distance
P = customised by learning
0...100% = percentage of travel stroke
DEFAULT
CONFIGURATION MIN
20
0
100
0
0
0
0
0
the 4 outputs which can be activated are:
OUTPUT 1 = STEP BY STEP, OUTPUT 2 = PARTIAL, OUTPUT 3
= OPEN, OUTPUT 4 = LIGHT ON-OFF.
MAX UNIT
0 900 s
0 30 s
% (step
10 100
of 10)
0 1
0 4
0 1
0 1
% (step
0 100
of 1)
