LW430
LWSTEM
Rubber Stop
8x (4 required)
Bent
Stretcher
2x
Library On Wheels
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at info@copernicused.com.
Have your packing slip ready for reference.
LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
Straight
Stretcher
2x
Straight
Stre
tcher
with Threaded Inserts
1x
Outside
Frame
2x
Tub Support
4x
Back Stop
2x
5" Caster
(2 with brakes)
4x
Please Recycle
Advertisement
Related Manuals for Copernicus Library On Wheels
Summary of Contents for Copernicus Library On Wheels
- Page 1 Stretcher Straight Stre tcher with Threaded Inserts Outside Frame Tub Support Rubber Stop 8x (4 required) Back Stop Bent Stretcher 5” Caster (2 with brakes) LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc. Please Recycle...
- Page 2 Customer Service & Warranty Information Dear Educator, Thank you for purchasing the Library On Wheels. We hope it meets your expectations and you and your students enjoy using it at your school. Every day we see and hear stories of teachers going above and beyond to help students thrive. Thank you so much for all you do –...
- Page 3 This product is intended for indoor comercial use only. To reduce the risk of fire or electric Indoor Use shock, do not expose this product to rain or moisture. The internal components are not Only sealed from the environment. LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
- Page 4 Contents - LWSTEM-CB Tiny Tub Rack Tiny Tub In LWSTEM M6 x 19mm Screw Box only (43219) Chart Loop Hook Whiteboard M6 Lock Washer (31062) (AC455) (43273) LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
- Page 5 Ÿ (Spanner Wrench) to fully tighten to frame. IMPORTANT: Routine Maintenance Verify regularly that casters are secure to the unit Ÿ Re-tighten if needed with Wrench Ÿ LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
- Page 6 Assemble with end frame and will be noted. hole indents facing outside of unit Please make sure to orient indent as instructed to make sure hardware holds LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
- Page 7 Rubber Stop 8x (4 required) Attach Tub Supports and Back Stops Push down firmly while twisting Hint: Moistening the rubber helps NOW TIGHTEN ALL FASTENERS FIRMLY (22 total) LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
- Page 8 You will need: (Not to Scale) Tiny Tub Rack Tiny Tub Install Tiny Tub Racks & Tubs You may now proceed to Step 3 of your LW430 assembly guide. LW430-LWSTEM - Version B - 25 October 2024 - Copernicus Educational Products Inc.
