Allegion VON DUPRIN HW7827 Installation Instructions Manual

*47986706*
47986706
Surface Vertical Rod Exit Device
QEL7827/27-F (Electric Latch Retraction) Surface Vertical Rod Exit Device
HH/HW7827/27-F (Hurricane Rated) Surface Vertical Rod Exit Device
Hurricane rated exit device requirements (when used with approved Allegion door applications)
Sexbolts
HH (Wind and
Impact rated)
HW (Wind Only)
Devices covered by these instructions:
7827 Surface Vertical Rod Exit Device
7827-F (Fire) Surface Vertical Rod Exit Device
CD7827 (Cylinder Dogging) Surface Vertical Rod Exit Device
• Screw chart ............................. 2
• Preparation chart .................... 3
• Device installation ............... 4-6
• Cut top rod ............................. 7
• Install rod extension ................ 7
• Optional equipment ............... 8
• Cut device .............................. 8
When installing a Wind and Impact-rated hurricane device (HH), sex bolts must be used. Sex
bolts are noted throughout the instructions where applicable. If through-bolting trims are used,
these trims are equivalent in function and are used in place of sex bolts.
Application Single door standard strike
7827
7827-F
7827
7827-F
1-877-671-7011
7827
Dogging Key
(use with non-fire devices
to lock down pushbar)
Index:
Top: 299F
Bottom: 304L
–
Top: 299
Bottom: 304L
–
Customer Service
www.allegion.com/us
Special tools needed:
5/64" hex wrench
#10-24 tap
Drill bits: #25, 1/8", 1/4", 5/16", 13/32"
Mullion Double door standard strike
–
Top: 299F
Bottom: 304L
–
–
Bottom: 304L
Top: 299F
–
Bottom: 304L
Installation Instructions
Top: 299
© Allegion 2024
Printed in U.S.A.
47986706 Rev. 07/24-b
