Allegion Briton 2130B Manual

SIZE 2-6 ADJUSTABLE BACKCHECK CLOSER

SIZE 2-6 ADJUSTABLE BACKCHECK & DELAYED ACTION CLOSER

PULL SIDE - REGULAR APPLICATION ( FIG. 1 )

ANGLE OF OPENING 180° SUBJECT TO HINGE & SURROUNDING STRUCTURE
R.H. DOOR
1
PEEL TEMPLATES OFF BACKING PAPER
POSITION ON DOOR/FRAME PILOT DRILL 6 HOLES
2
FIT ARM BRACKET ASSEMBLY (2 SCREWS)
3
FIT MAIN ARM ASSEMBLY TO MECHANISM (90º)
SECURELY TIGHTEN FIXING SCREW WITH SPANNER
4
OPEN DOOR TO ENGAGE SECONDARY ARM STRIP AND TUBE
5
CLOSE DOOR AND SET SECONDARY ARM AT 90º TO DOOR FACE
SECURELY TIGHTEN CLAMP BOLT WITH SPANNER
BACKCHECK CLOSER
DOOR
LATCH SPEED BACKCHECK
1
2
6

IF NECESSARY ADJUST POWER AND DOOR SPEEDS

B
E
C
D
E
FIT MECHANISM BRACKET (2 SCREWS)
90º
90º
LOCATE MECHANISM ASSEMBLY ON
BRACKET AND SECURE ( 2 SCREWS )
PEEL OFF TEMPLATES
90º 90º
BACKCHECK & DELAYED
ACTION CLOSER
DOOR
LATCH SPEED DELAY BACKCHECK
3
4
A
E
STANDARD OPTIONAL
COVER COVERS
FIT COVER TO CLOSER
7
FOLLOWING STEPS SHOWN
(2 SCREWS)
L.H. DOOR
1
2
3
4
5
POWER ( FIG.1 )
FACTORY SET TO SIZE 4
NUMBER
CLOSER
OF TURNS
POWER SIZE
-
(APPROX)
2 -6
3 -3
+
4 0
5 +6
6 +12
6
B
A
C
D
E
7

WARNING

DOOR CLOSER POWER #1 & 2 AND THOSE SUPPLIED
WITH MECHANICAL HOLD OPEN DEVICES MUST NOT BE
INSTALLED ON FIRE / SMOKE DOORS.
CLOSER
POWER
DOOR
SIZE
#1
20kg
750
MAX
#2
40kg
850
MAX
#3
60kg
950
MAX
#4
80kg
1100
MAX
#5
100kg
1250
MAX
#6
120kg
1400
MAX
2130/108/00
REVISION A
