LCN Benchmark
Page 1 of 20
Allegion
Low Energy Operators
Installation Manual
LCN Low Energy Operators should
be installed in accordance with the
current Allegion LCN installation
instructions.
Commissioning and Servicing of
installed units must be carried out by
an Allegion Approved, Authorised
Technician
16-20 Third Ave, Sunshine, Vic, 3020
Tel: 1800 098 094
Email: auinfo@allegion.com
December 2014
AU9100 Series
®
Ver 4
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allegion LCN Benchmark AU9100 Series
Summary of Contents for Allegion LCN Benchmark AU9100 Series
- Page 1 AU9100 Series ® Low Energy Operators Installation Manual LCN Low Energy Operators should be installed in accordance with the current Allegion LCN installation instructions. Commissioning and Servicing of installed units must be carried out by an Allegion Approved, Authorised Technician...
-
Page 2: Table Of Contents
GENERAL ............................2 REPLACEMENT PARTS AND SYSTEM COMPONENTS .............. 3 PRE-INSTALLATION SITE AND PRODUCT CHECK ..............4 OPERATOR INSTALLATION ......................5 WIRING ..............................7 ARM AND COVER INSTALLATION ....................8 OPERATIONAL CHECK........................10 OPERATOR ADJUSTMENT ......................11 RELEASE FOR SERVICE ......................... 13 LCN AU9100 (Briton 2500) V4 SOFTWARE .................. -
Page 3: Replacement Parts And System Components
REPLACEMENT PARTS AND SYSTEM COMPONENTS 9130 Series 9140 Series - (ANCLR or ANDKB only) - (ANCLR or ANDKB only) 9130-3077T........Standard Arm 9140-3077 ........Regular Arm 9130-3077PLCM..Standard Arm w/Track 9140-3077L........Long Arm 9130-3038..........Track 9140-72MC*........Metal Cover 9130-72MC*........Metal Cover 9140-72FC* ......Full Metal Cover 9130-72FC* ......Full Metal Cover 9140-MS........Screw Pack 9130-MS........Screw Pack 9140-77..........Main Arm... -
Page 4: Pre-Installation Site And Product Check
PRE-INSTALLATION SITE AND PRODUCT CHECK Check that the product model is correct for the required application Check that all parts listed for the installation are received Check architectural drawings and final approved shop drawings for position of frame and structural openings Check header and frame dimensions and required clearances Clearances for pull system... -
Page 5: Operator Installation
OPERATOR INSTALLATION Remove control box from mounting bracket, then remove Motor/Gearbox from bracket Prepare header frame Pull system …………………See Page 5 Push system…………………See Page 6 NOTE NOTE For push units with a reveal greater than 150 mm refer to installation sheet included in the extended arm Packaging. - Page 6 OPERATOR INSTALLATION (Cont) Push System Framed Header and Door Preparation REVEAL Butt Hung/Offset Pivot Centre Pivot DIM A DIM A Page 6 of 20 December 2014 Ver 4...
-
Page 7: Wiring
WIRING CAUTION • Make sure all wires are properly dressed and secured to prevent interference • Route all wiring away from moving parts, sharp edges, and heat sources • Use copper conductors only • Do not modify the factory wiring or connect into existing electrical circuits or devices AUTION Refer to the appropriate wiring diagram for the standard control box (Page 22) or the... -
Page 8: Arm And Cover Installation
ARM AND COVER INSTALLATION WARNING • Keep hands, clothing, wires, tools, ETC away from the operator motor when the operator is turned on RNING Make sure the operator power switch is turned OFF Install a jumper across the control box MAIN ACT T28 and COMMON T27 Turn the operator power switch on. - Page 9 ARM AND COVER INSTALLATION (Cont) 6.5.2 For pull systems, slide the pull arm roller into the track, insert a track cap on each end of the track, and attach the track to the door. Pull Arm Adjust the arm 6.6.1 For pull systems, remove the locking screw from the arm 6.6.2 For the push system remove the locking screw from the arm Pull Arm...
-
Page 10: Operational Check
OPERATIONAL CHECK Set the Key switch to Auto (1 Way) and turn on the operator power switch Activate the operator using the activation device, the operator will perform one sizing cycle Sizing cycle: Occurs after a legitimate activation signal is received, after power has been turned on. During the size cycle, the door opens and closes one time. -
Page 11: Operator Adjustment
OPERATOR ADJUSTMENT See table below and diagrams on page 18 for operator feature adjustment. After adjustment, cycle the door several times and check for proper operation, then continue with step 6.11 on page 9. NOTE Adjust operator for the slowest operation practical in accordance with the latest AS_5007 standards for powered doors for pedestrian access and egress. - Page 12 OPERATOR ADJUSTMENT (Cont) Page 12 of 20 December 2014 Ver 4...
-
Page 13: Release For Service
RELEASE FOR SERVICE Remove all tools, installation equipment, and debris from the vicinity of the door. Install all safety, traffic control, and instruction labels on the door as required by the latest AS_5007 Standard. Failure to do this leaves the installer LIABLE for any accident that might occur. -
Page 14: Lcn Au9100 (Briton 2500) V4 Software
10 LCN AU9100 (Briton 2500) V4 SOFTWARE 10.1. OPERATION ....................15 10.1.1. Sizing ......................15 10.1.2. Auto Reverse on open ................... 15 10.1.3. Standard operation ..................15 10.2. FUNCTION SELECTION................16 10.2.1. Standard (0) ....................16 10.2.2. Lock in OFF Only (1) ................... 16 10.2.3. -
Page 15: Operation
10.1 OPERATION 10.1.1 Sizing From start up (size) the door will activate from morning entry (24Hrs,T9, T10) regardless of key switch position, 1 Way input (T27,T28) with key switch in one way. 2 Way input (22, T23) with key switch in two way, or key switch Hold Open. -
Page 16: Function Selection
General 24Hr operates the door regardless of key switch position the door will drive open and remain in the open position as long as the contact is made (Program 4 is the exception) Key switch position OFF no activation or safety operates. Electric lock operates when door closed dependant upon function selection Electric lock operation is set from the function selector the time delay is fixed Key switch Position 1 Way the activation from internal Activate (T27, T28) safety... -
Page 17: Function Chart
10.3 FUNCTION CHART Program Operation Eyetech Act T1,T2 Eyetech Saf T5,T6 Standard F/A T9,T10 1 Way T27,T28 Door open T14 Key switch off T12 2 Way T22,T23 T8 Not Used Locking in OFF only As Std Door locks in OFF Only As Std Locking Auto only Door Locks in AUTO Only... -
Page 18: Control Box Setup
10.4 CONTROL BOX SETUP Page 18 of 20 December 2014 Ver 4... -
Page 19: Lcn Au9100 (Briton 2500) Ii Wiring
10.5 LCN AU9100 (Briton 2500) ii WIRING Page 19 of 20 December 2014 Ver 4... - Page 20 10.6 LCN AU9100 (Briton 2500) ii Terminal Block Page 20 of 20 December 2014 Ver 4...
