Step 1: Check what's in the box
KT-2010SH:
10" Touch Panel
Step 2: Get to know your KT-2010SH
#
Feature
1
Display
2
Proximity Sensor
3
Reset
4
Home Button
5
Restore Factory Reset Button
6
USB 3.0 Port
USB Type-C Port
7
LAN 1G(PoE) RJ-45 Port
8
9
Kensington Lock
10
12V/2A DC Connector
KT-2010SH Quick Start
KT-2010SH Quick Start Guide
This guide helps you install and use your
Go to
https://www.kramerav.com/downloads/kt-2010sh
firmware upgrades are available.
1 Quick start guide
Function
Touch panel
Automatically adjusts the screen brightness and camera according to the room
lighting conditions.
Located on the topside. Insert a pin and hold for a few seconds to restart.
Press to wake up / darken the screen.
Insert a pin and hold for 22 seconds to reset the device to factory default values.
Multipurpose port for external connection.
Multipurpose port for external connection.
Connect to the LAN for network communication.
KT-2010SH
port. Optionally, you can connect the power adapter too (as backup).
Anti-theft security slot for locking the device.
Connect to the power adapter (optional, purchased separately).
KT-2010SH
for the first time.
to download the latest user manual and check if
Table stand / Wall mount
are powered by PoE (power over ethernet) delivered through the LAN
P/N: 2 9 0 0 - 3 0 1 7 0 8 QS
Mounting accessories
Rev: 2
Advertisement
Related Manuals for Kramer KT-2010SH
Summary of Contents for Kramer KT-2010SH
- Page 1 Step 1: Check what’s in the box KT-2010SH: 10" Touch Panel 1 Quick start guide Table stand / Wall mount Mounting accessories Step 2: Get to know your KT-2010SH Feature Function Display Touch panel Proximity Sensor Automatically adjusts the screen brightness and camera according to the room lighting conditions.
- Page 2 M3 screw. The table stand and touch panel are now ready for use. For optimum range and performance use the recommended Kramer cables available at www.kramerav.com/product/KT-2010SH Using third-party cables may cause damage!
- Page 3 3. Use the provided M3 screw to secure the touch panel to the wall bracket and back cover. The touch panel is mounted. For optimum range and performance use the recommended Kramer cables available at http://www.kramerav.com/product/KT-2010SH Using third-party cables may cause damage!
- Page 4 By default, KT-2010SH displays the Kramer Agent interface that turns the touch panel into a controllable device interacting with Kramer Brain / Virtual Brain room control software. The Brain IP needs to be setup (see step 6). The following setup steps are recommended before using your touch panel: 1.
