2. Hanging the Fan
REMEMBER to turn off power at the breaker.
Follow the steps below to hang your fan properly:
1. Disconnect power at the breaker to the fan location.
A licensed electrician must install the fan (Fig. 2).
2. Remove 1 of 2 screws from the bottom of mounting bracket and
save for use in section 9. Loosen the other screw (Fig. 2).
3. Pass the 120-volt supply wires through the center hole in the
ceiling mounting bracket as shown in (Fig.2A).
4. Secure the mounting bracket to the ceiling outlet box with the
screws and washers provided with your outlet box (Fig. 2A).
5. Carefully remove and discard the blue shipping cap from
the top of the motor housing, ensuring that the lead wires
and safety cable do not become twisted.
6. Remove the 3 screws from the blue shipping cap on the
bottom of the motor housing and keep them for use with
the light kit adapter plate. Discard the blue shipping cap.
7. Take out the set screw located in the hanger ball, lower the
hanger ball and remove the cross pin. Remove the hanger
ball from the hanger ball/downrod assembly (Fig. 2B).
8. Remove the clevis pin and cotter pin, and loosen the two
collar screws from the motor collar (Fig. 2B).
9. Carefully feed the motor wires and safety cable up through
the downrod. Thread the downrod into the collar.
10. Align the holes of downrod and collar and insert the cotter
pin and clevis pin. Tighten the two collar screws (Fig. 2B).
WARNING:
and/or tighten the screws could result in the fan loosening
and possibly falling.
12 Osprey Instructions
Failure to properly install the cotter pin
FR-W1817
