Osprey
Installation Instructions
works with the
Google Assistant

Advertisement

loading
Need help?

Need help?

Do you have a question about the Osprey and is the answer not in the manual?

Questions and answers

Related Manuals for Modern Forms Osprey

Summary of Contents for Modern Forms Osprey

  • Page 1 Osprey Installation Instructions works with the Google Assistant...
  • Page 2 Please read and save these instructions before installation DO NOT RETURN TO STORE Osprey Instructions FR-W1817...
  • Page 3 For fast service have the following information below when you call: Model Name and Number 2. Part Number and Part Description 3. Date Of Purchase and Purchase Location 1-866-810-6615 option 1 MON-FRI 8AM-8PM EST Email: fansupport@modernforms.com Osprey Instructions 3 FR-W1817...
  • Page 4 The wires should be spread apart with the grounded conductor and the equipment-grounding conductor on one side of the outlet box, and the ungrounded conductor on the other side of the outlet box. All set screws must be checked and re-tightened where necessary before installation. Osprey Instructions FR-W1817...
  • Page 5 Modern Forms. Substitution of parts or accessories not designated for use with this product by Modern Forms could result in personal injury or property damage and will void the warranty. Contact an authorized dealer or the manufacturer if any parts are damaged or missing.
  • Page 6 AC fans MOTOR Bluetooth Remote Control Dims light to 1% | ON/OFF 6 fan speeds F-RCBT-WT White Accessories: personalize your experience Bluetooth Wall Control Dims light to 1% | ON/OFF 6 fan speeds | Sold separately F-WCBT-WT White Osprey Instructions FR-W1817...
  • Page 7 5. Finishing the Installation 6. Attaching the Fan Blades 7. Installing the Adapter Plate 8. Installing the LED Luminaire Module 9. Controlling the Fan 10. Reset 11. Breeze Mode 12. Application 13. Accessories 14. Troubleshooting 30-32 Tools Required Osprey Instructions 7 FR-W1817...
  • Page 8 Screws with lock washers (10) • 10x4mm flat washers (2) Before discarding packaging materials be certain all parts have been removed. Place the parts from the hardware bag into a small container to keep them from being lost. Osprey Instructions FR-W1817...
  • Page 9 Hanging Weight: 17 lbs IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place. Osprey Instructions 9 FR-W1817...
  • Page 10 The sloped ceiling kit (sold separately) is required for sloped ceiling applications, and will accommodate slopes up to 45° (Fig. 1B). NOTE: You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling (Fig. 1B). Osprey Instructions FR-W1817...
  • Page 11 Support Brace 2. Outlet Box 3. Joist Outlet Box Support Ceiling Max 30° Angle Support Brace 2. Mounting Bracket 3. Recess Outlet Box Outlet Box Osprey Instructions 11 FR-W1817...
  • Page 12 10. Align the holes of downrod and collar and insert the cotter pin and clevis pin. Tighten the two collar screws (Fig. 2B). WARNING: Failure to properly install the cotter pin and/or tighten the screws could result in the fan loosening and possibly falling. Osprey Instructions FR-W1817...
  • Page 13 3. Mounting Bracket 2. Screw 4. Mounting Screws (supplied with outlet box) Hanger Ball/ Mounting Bracket 2. Downrod 3. Canopy 4. Canopy Screw Cover 5. Coupling Cover 6. Collar Cotter Pin 8. Clevis Pin 9. Screws Osprey Instructions 13 FR-W1817...
  • Page 14 (Fig. 2D). NOTE: A Safety cable is required for all installations in Canada. Safety cable is required for ceiling fan and light combinations over 35 lbs. in both flush and downrod models in the United States. Osprey Instructions FR-W1817...
  • Page 15 Motor Wires 2. Safety Cable 3. Downrod 4. Canopy 5. Canopy Screw Cover 6. Coupling Cover Wood Screw 2. Safety Cable Osprey Instructions 15 FR-W1817...
  • Page 16 Connect the black (hot) wire from the ceiling to the black wire marked “AC in L” from the receiver. 8. Connect the white (neutral) wire from the ceiling to the white wire marked “AC in N” from the receiver. Osprey Instructions FR-W1817...
  • Page 17 Follow the steps above to connect the fan to your household wiring. Use the plastic wire nuts with your fan. Secure the plastic wire nuts with electrical tape. Make sure there are no loose strands or connections. Osprey Instructions 17 FR-W1817...
  • Page 18 Fasten the wall plate to the wall mounting plate (Fig. 4A). to Fan House Wires Wall Switch Wires (Hot) (Hot In) (Neutral) (Neutral) (Copper/Ground) (Ground) Fan Switch leg (Hot out to Fan) From Breaker * Home Wiring may vary Osprey Instructions FR-W1817...
  • Page 19 Individually pair each of the wall controls with the fan receiver using the pairing instruction. See page 24. If Applicable Wallcontroller 1 Wallcontroller 2 Wallcontroller 3 Wall Control 3 Wall Control 1 Wall Control 2 Line/Hot Green (Green or Bare) Neutral/White Osprey Instructions 19 FR-W1817...
  • Page 20 Turn the mounting plate until the adapter plate locks in place at the narrow section of the key holes (Fig. 7). 3. Tighten the two mounting ring screws previously loosened and the one previously removed to secure adapter plate. Osprey Instructions FR-W1817...
  • Page 21 Outlet Box 2. Hanger Bracket 3. Screws 4. Canopy 5. Canopy Screw Cover 6. Blade Mounting Ring 8. Adapter Plate Osprey Instructions 21 FR-W1817...
  • Page 22 Secure by tightening the 2 screws previously loosened and the one previously removed (Fig. 8). 5. Raise fresnal glass shade up against the luminaire module, and secure it to fan by turning acrylic shade clockwise until snug. Do not overtighten. Osprey Instructions FR-W1817...
  • Page 23 Osprey Instructions 23 FR-W1817...
  • Page 24 NOTE: Pairing must be completed within three (3) minutes of powering the fan. Synchronizing Control Across Multiple Fans If you are controlling multiple fans with one controller, fans/lights may be synced by referring to Fig. 9B and instructions on the next page. Osprey Instructions FR-W1817...
  • Page 25 All fans will be set to summer mode (CCW rotation). This will bring all fans controlled by the remote into sync. Osprey Instructions 25 FR-W1817...
  • Page 26 In addition to the included remote control, you can control your fan with a wall control (sold separately) or through the Modern Forms app. To use the Modern Forms app, download it for free from the App Store or Google Play.
  • Page 27 3 beeps indicating the reset receiver emits 3 beeps indicating the reset Scan and follow prompts for multilingual instruction options and Smart Fan FAQs: Spanish For detailed Instructions and Smart Home Device Integration French Osprey Instructions 27 FR-W1817...
  • Page 28 13. Accessories personalize your experience Bluetooth Remote Control Dims light to 1% | ON/OFF 6 fan speeds F-RCBT-WT White Bluetooth Wall Control Dims light to 1% | ON/OFF 6 fan speeds | Sold separately F-WCBT-WT White Osprey Instructions FR-W1817...
  • Page 29 Connects two downrods XF-I Downrod XF-12 - 12” Downrod | XF-18 - 18” Downrod XF-24 - 24” Downrod | XF-36 - 36” Downrod XF-48 - 48” Downrod | XF-60 - 60” Downrod XF-72 - 72” Downrod Osprey Instructions 29 FR-W1817...
  • Page 30 4. Make sure the fan blades are properly aligned and securely fastened to the motor housing assembly/blade arms. 5. Make sure the gaps between the blades are evenly distributed or make sure you are using an approved cUL/UL listed outlet boxand it is installed correctly. Osprey Instructions FR-W1817...
  • Page 31 Your fan supports connection with 2.4GHz 802.11b/g/n networks. Confirm your network is compatible by checking your router settings or contact your router manufacturer. 2. Make sure your network’s SSID is not hidden. 3. Your fan does not support 5 GHz network connectivity. connection. Osprey Instructions 31 FR-W1817...
  • Page 32 10 seconds and back on. Alternately, you can use the circuit breaker the fan is connected to by toggling it off for 10 seconds and back on. If your fan is wired through a Modern Forms wall control (P/N: F-WCBT-WT) pull the Air-Gap Switch on your wall control, wait 10 seconds, and re-insert.
  • Page 33 What is Pairing? Pairing is the process of connecting your Modern Forms remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
  • Page 34 Notice of a defect in writing must be received by Modern Forms within five (5) years from the date of purchase (or according period of time as outlined by material). Excluded from warranty are any 3rd party component which carries its own manufacturer’s warranty.
  • Page 35 La notificación de un defecto por escrito debe ser recibida por Modern Forms dentro de los cinco (5) años a partir de la fecha de compra (o según el período de tiempo indicado en el material). Quedan excluidos de la garantía todos los componentes de terceros que tengan la garantía de su propio fabricante.
