Elite Industries EL-141 Assembly Instructions

23 1/4"
43"
21"
Hardware for cabinet assembly
A B
16
Connecting
Casters
Bolts
J K
16
Plastic
Wooden Dowels
Camlock Covers
• Carefully read and follow these instructions
for assembly.
• Please handle parts carefully, some parts may
be heavy.
• To protect the unit and your flooring surface
we recommend working on a padded or car-
peted area, you may also use the open box
the unit came in for this purpose.
• For proper construction & integrity/assembly
and for TV weight support and safety, all con-
SPECIAL NOTE
In all steps involving camlocks, please
note the correct position of the camlock in the
illustration at the left. Check all camlocks before
aligning and joining pieces together.
IMPORTANT: Throughout assembly
of the unit, camlocks must be inserted with
the openings facing the nearest unfinished
edge and screwdriver slot parallel to
unfinished edge.
474263
PLEASE CALL 1-800-ELITE-48. CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:45 PM M-F
Thank you for purchasing this Elite product. You will need the following tools:
Phillips Head Screw Driver • Straight Blade Screw Driver • Rubber Padded Hammer or Mallet
Assembly Instructions
Audio Rack on Casters
19 1/4"
EL-141 and EL-141S
PLEASE NOTE:
The following numbers and let-
ters correspond to the sketch-
es in this instruction booklet.
CABINET PARTS:
1. Top Panel
2. Bottom Panel
3. Left and Right Side Panels
4. Two Vertical Mouldings
5. Three Adjustable Shelves
6. Back Panel (2 identical)
7. Glass Door
D
C
16
4
5/8" Wood Screws
Magnetic
for Casters
Touch Latch
S
1
Hardware
for door
4
8
assembly
IMPORTANT NOTES & CAUTIONS/WARNINGS
nections need to be sufficiently tight.
However, do not over-tighten connections to
the point of stripping screw threadings. Parts
are designed to fit together tightly, however,
avoid excessive force but rather align & fit
panels together methodically and with
patience.
• For some heavy or large units, it may be rec-
ommended for 2 people to work together on
this assembly.
PLEASE DO NOT RETURN UNIT TO STORE FOR PARTS & CUSTOMER SERVICE.
VISIT OUR WEBSITE AT: www.elite-inds.com
(identical)
(identical)
(identical)
E
1 2
1/2" Wood Screws
for Magnet
T
1
2
Glass Door
Protective Plates
Hinges
CAMLOCK/CONNECTING BOLT PROCEDURE
1
ALIGN CAMLOCK &
CONNECTING BOLT
Page 1/4
3
5
5
4
5
2
F
G
16
5/8" Wood Screws
Camlocks
for Back Panel
U
V
1
Foam
Metal Strike Plate
Protective Pad
• It is extremely important to attach the BACK
PANEL as instructed within this manual. Such
panels are crucial for the stability and struc-
tural support of the unit.
• Please read additional important safety
information at the end of this instruction
manual.
• We urge you to keep this manual with your
unit for future reference.
2
JOIN PIECES
TOGETHER
1
6
6
3
4
7
H
12
18
1" Long
Shelf Pins
W
1
2
Plastic Bushings
3
TURN CAMLOCKS
180° CLOCKWISE
USING A FLATHEAD
SCREWDRIVER
04.10.07
