Elite Industries EL-783 Assembly Instructions

Thank you for purchasing this Elite product. You will need the following tools:
Phillips Head Screw Driver • Straight Blade Screw Driver • Rubber Padded Hammer or Mallet
Assembly Instructions
36" WIDE HIGH BOY TV STAND AUDIO/VIDEO COMBINATION UNIT
OVERALL DIMENSIONS (EL-783, EL-743): 31" H x 36" W x 18 1 /2" D
OVERALL DIMENSIONS (EL-743C): 31" H x 36" W x 21 2 /3" D
EL-783: Oak Veneer (Shaped Leg & Rail)
EL-743: Wenge (Straight Leg & Rail)
EL-743C: Wenge (Straight Leg & Rail, Modified Top)
NOTE: Assembly instructions for EL-783, EL-743 and EL-743C are the same. The shape of the
leg on Side Panels (3, 4) and the shape of the Bottom Front Rail (8) differ for the EL-783 and
the EL-743. EL-743C has the Straight Leg, Straight Rail, and the Modified Top Panel.
EL-783
OAK VENEER
Shaped Leg
Shaped Rail
PARTS
1. Top Panel
2. Bottom Panel
3. Left Side Panel
4. Right Side Panel
5. Fixed Shelf
Hardware for unit assembly
B
A 16
Connecting
Bolts
D 15 E
1" Screws for
Back Panel
Hardware for door assembly
G
Hinge Pairs G1 + G2
G1 is attached to Door.
G2 is attached to Side Panel.
G1
2 FACTORY
INSTALLED SCREWS
K
J 8
1" Screws for
middle hole
5/8" Screws for
to attach G2
attaching G1
EL-743C
WENGE
Straight Leg
Straight Rail
Modified Top
6. Adjustable Shelf
7. Back Panel
8. Bottom Front Rail
9. Glass Door with Wooden
Frame (2 identical)
16
C
Wooden
Camlocks
Dowels
F
4
Shelf Pins Plastic Covers
for Camlocks
H
4
G2
Machine Screws
HOLE FOR
for Door Handle
SCREW K
4 L
PLEASE DO NOT RETURN UNIT TO STORE FOR PARTS & CUSTOMER SERVICE.
PLEASE CALL 1-800-ELITE-48. CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:45 PM M-F
VISIT OUR WEBSITE AT: www.elite-inds.com
EL-743
WENGE
Straight Leg
Straight Rail
3
12
8
9
4 Z
2"
Door Stop
2
Door Handle
Page 1/4 06.11.08
18 1 "
/
2
EL-783, EL-743
TOP
1
EL-783 & EL-743
5
6
2
8
9
2
IMPORTANT NOTES & CAUTIONS/WARNINGS
• Carefully read and follow these instructions for assembly.
• Please handle parts carefully, some parts may be heavy and can have
sharp edges – we recommend possibly using cloth protective gloves
for extra protection.
• To protect the unit and your flooring surface we recommend working
on a padded or carpeted area, you may also use the open box the
unit came in for this purpose.
• For proper construction & integrity/assembly and for TV weight sup-
port and safety, all connections need to be sufficiently tight. However,
do not over-tighten connections to the point of stripping screw
threadings. Parts are designed to fit together tightly, however, avoid
excessive force but rather align & fit panels together methodically and
with patience.
• For some heavy or large units, it may be recommended for 2 people
to work together on this assembly.
• It is extremely important to attach the BACK PANEL as instructed
within this manual. Such panels are crucial for the stability and struc-
tural support of the unit.
• Please read additional important safety information at the end of
this instruction manual.
• We urge you to keep this manual with your unit for future reference.
36"
EL-743C TOP
36"
31"
EL-783 LEGS
EL-743, EL-743C
LEGS
1
EL-743C
7
4
