Elite Industries EL-785 Assembly Instructions

Assembly Instructions
47" WIDE TV STAND, AUDIO/VIDEO COMBINATION UNIT
OVERALL DIMENSIONS: 20
EL-785: Oak Veneer (shaped leg & rail)
EL-745: Wenge (straight leg & rail)
NOTE: Assembly instructions for both the EL-785 and the EL-745 are the same. The shape of the
leg on Side Panels (3, 4) and the shape of the Bottom Front Rail (8) are the only differences.
EL-785 OAK VENEER
Shaped Leg, Shaped Rail
PARTS
1. Top Panel
2. Bottom Panel
3. Left Side Panel
4. Right Side Panel
5. Vertical Divider Panel
6. Glass Adjustable Shelf (2 identical)
7. Back Panel
8. Bottom Front Rail
9. Glass Door with Wooden Frame (2 identical)
Hardware for unit assembly
A 16 B
Connecting
Bolts
C 12
D
Wooden
1" Screws for
Dowels
Back Panel
E 8 F
Shelf Pins Plastic Covers
for Camlocks
Hardware for door assembly
G
Hinge Pairs G1 + G2
G1 is attached to Door.
G2 is attached to Side Panel.
G1
2 FACTORY
INSTALLED SCREWS
J 8 K
1" Screws for
middle hole
5/8" Screws for
to attach G2
attaching G1
Thank you for purchasing this Elite product. You will need the following tools:
Phillips Head Screw Driver • Straight Blade Screw Driver • Rubber Padded Hammer or Mallet
3 /
" H x 47" W x 18
4
EL-745 WENGE
Straight Leg, Straight Rail
16
Camlocks
11
8
4 H
G2
Machine Screws
HOLE FOR
for Door Handle
SCREW K
4 L
PLEASE DO NOT RETURN UNIT TO STORE FOR PARTS & CUSTOMER SERVICE.
PLEASE CALL 1-800-ELITE-48. CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:45 PM M-F
VISIT OUR WEBSITE AT: www.elite-inds.com
1 /
" D
2
3
6
9
9
8
4
2"
2
Door Handle
Page 1/4 2.11.08
/
18 1 "
2
1
5
6
2
IMPORTANT NOTES & CAUTIONS/WARNINGS
• Carefully read and follow these instructions for assembly.
• Please handle parts carefully, some parts may be heavy and can
have sharp edges – we recommend possibly using cloth protec-
tive gloves for extra protection.
• To protect the unit and your flooring surface we recommend work-
ing on a padded or carpeted area, you may also use the open box
the unit came in for this purpose.
• For proper construction & integrity/assembly and for TV weight
support and safety, all connections need to be sufficiently tight.
However, do not over-tighten connections to the point of stripping
screw threadings. Parts are designed to fit together tightly, howev-
er, avoid excessive force but rather align & fit panels together
methodically and with patience.
• For some heavy or large units, it may be recommended for 2 peo-
ple to work together on this assembly.
• It is extremely important to attach the BACK PANEL as instructed
within this manual. Such panels are crucial for the stability and
structural support of the unit.
• Please read additional important safety information at the end of
this instruction manual.
• We urge you to keep this manual with your unit for future reference.
47"
/
3
20 "
4
EL-785
EL-745
7
4
