Elite Industries EL-907 Assembly Instructions

ASSEMBLY INSTRUCTIONS
45" WIDE TV STAND, AUDIO/VIDEO COMBINATION UNIT
DESIGNED FOR PLASMA, LCD, DLP & THIN FLAT-PANEL TV'S
OVERALL DIMENSIONS: 26" H x 45" W x 21
PARTS
1. Glass Top Panel Surface (14" x 45")
2. Glass Shelf
3. Wooden Shelf (2 identical)
4. Small Metal Frame for Glass Top Panel Surface
5. Large Metal Frame for Glass Shelf
6. Front Left Leg
7. Front Right Leg
8. Back Left Leg
9. Back Right Leg
10. Support Rail (2 identical)
11. Wire Management Channel
Hardware for unit assembly
A B
8
Connecting
Bolts
C D
8
Wooden
Dowels
E
F
4
1-3/16" Bolts for
Metal Frames
G H
12
Self-Adhesive
Spacer Disk for
2" Screw for Bottom
under Glass
J
K
4
11/16" Screw for
Bushings for Large
Wire Management
FOR PARTS & CUSTOMER SERVICE PLEASE CALL 1-800-ELITE-48
CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:45 PM M-F
Thank you for purchasing this Elite product. You will need the following tools:
Phillips Head Screw Driver • Straight Blade Screw Driver • Rubber Padded Hammer or Mallet
EL-907
: Wenge Melamine
(A rich, deep brown-black, wood-grain finish)
EL-947
: High Gloss Black Lacquer
EL-957
: Gray Melamine
8
Camlocks
1
Hex Key
Tool
8
Plastic Glass
Cushion
IMPORTANT NOTES & CAUTIONS/WARNINGS
• Carefully read and follow these instructions for assembly.
• Please handle parts carefully, some parts may be heavy and can
have sharp edges – we recommend possibly using cloth protective
gloves for extra protection.
• To protect the unit and your flooring surface we recommend working
4
on a padded or carpeted area, you may also use the open box the
unit came in for this purpose.
• For proper construction & integrity/assembly and for TV weight
Support Rails
support and safety, all connections need to be sufficiently tight.
However, do not over-tighten connections to the point of stripping
screw threadings. Parts are designed to fit together tightly, however,
BLACK
avoid excessive force but rather align & fit panels together methodi-
cally and with patience.
2 • For some heavy or large units, it may be recommended for 2 people
to work together on this assembly.
11/16" Threaded
• Please read additional important safety information at the end of
this instruction manual.
Metal Frame • We urge you to keep this manual with your unit for future reference.
474534
PLEASE DO NOT RETURN UNIT TO STORE
3 /
"D
4
1
2
8
10
6
Page 1/4
14"
3
3
7
SPECIAL NOTE for EL-947
Legs have a foil wrapping to
protect the High Gloss Finish.
Please remove this wrapping
Step #1, Leg Preparation.
7.10.06
45"
26"
3
21 / "
4
11
4
5
9
10
before proceeding with
