Elite Industries CREDENZA EL-1296 Assembly Instructions

Phillips Head Screw Driver • Straight Blade Screw Driver • Rubber Padded Hammer or Mallet
ASSEMBLY INSTRUCTIONS
64-1/3" WIDE "CREDENZA" UNIT
TV STAND & AUDIO RACK COMBO
Model EL-1296 Black Ash Melamine
OVERALL DIMENSIONS:
16-1/2" H x 64-1/3" W x 19" D
CABINET PARTS
1. Bottom Wooden Panel
2. Corner Legs (4 identical)
3. Side Panels (2 identical)
4. Vertical Divider Panels
(2 identical)
5. Top Wooden Panel
6. Back Panel
7. Adjustable Shelves
(2 identical)
8. Glass Doors (2 identical)
9. Drawer Face Panels
(2 identical)
10. Drawer Back Panels
(2 identical)
11. Drawer Side Panels
(4 identical)
12. Drawer Bottom Panels (2 identical)
HARDWARE FOR CABINET ASSEMBLY
A - (16) B - (16)
Connecting Bolts
Camlocks
H - (2) I - (4)
1/2" Wood Screws
for Magnetic
Magnetic
Touch Latch
Touch Latch
S - (5) T - (4)
Plastic Feet for
1-3/4" Screws
Corner Legs
for Legs
HARDWARE FOR DRAWER ASSEMBLY
C - (8)
1-1/4"
Drawer Handles
Wooden Dowels
477784
PLEASE CALL 1-800-ELITE-48. CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:30 PM M-F
Thank you for purchasing this Elite product. You will need the following tools:
3
7
8
C - (24)
1-1/4" Wooden
Dowels
L - (2)
8
2
Glass Door Hinges
U - (1)
Hex Key
W - (2)
X - (16)
CHROME
1-1/4" Screws for
Drawer Side Panels
with Screws
PLEASE DO NOT RETURN UNIT TO STORE FOR PARTS & CUSTOMER SERVICE.
VISIT OUR WEBSITE AT: www.elite-inds.com
5
4
8
D - (4)
1-1/2"
Wooden Dowels
Camlock Covers
for Corner Legs
M - (4)
2
Protective
Plates
V - (1)
Adjustable
Center Leg
Each rail set
includes
right and left
Y-Rails and
right and left
Z-Rails.
There are 2
rail sets.
Page 1/4
6
4
3
7
1
2
E - (8) F - (8)
Plastic 1" Metal
Shelf Pins
N - (2) O - (2)
Foam
Metal Strike
Protective Pads
Plates
HARDWARE FOR DRAWER RAILS
Y1 - (8)
1/2" Chrome Screw to attach Y-Rails
to Vertical Dividers
Z1 - (12)
5/8" Chrome Screw to attach Z-Rails
and Drawer Bottom Panels
10
11
11
12
9
G - (20)
BLACK
5/8" Screws
for Back Panel
P - (4)
Plastic
Bushings
12.03.10
