Fenix HM71R Manual page 3

With the lamp switched off, press and hold the switch for 0.5 seconds to enter Spotlight mode, and
double click the switch to enter Floodlight mode.
With the lamp switched on, press and hold the switch for 1.2 seconds to enter the other mode.
Output Selection
In Spotlight mode, single click the switch to cycle through Low→Med→High→Turbo.
In Floodlight mode, single click the switch to cycle through Read→Low→Med→High.
Lock/Unlock
Lock: when the lamp is switched off, press and hold the switch for 3 seconds, the lamp will blink 4 times
on Read mode to indicate locked status.
Unlock: when the lamp is locked, press and hold the switch for 3 seconds, the lamp will be activated with
4 one-second Read mode blinks and activated on Read mode.
In locked status, clicking the switch will activate 4 one-second blinks on Read mode to indicate locked
status.
Intelligent Memory Circuit
The headlamp memorizes the last selected output of Spotlight mode. When turned on again the
previously used output of Spotlight mode will be recalled. Each time the Floodlight mode is entered with
Read.
* If turning off the lamp in the Turbo of the Spotlight mode, When turned on again the High output level
of Spotlight mode will always be recalled.
Battery Specifications
Type
Fenix ARB-L21 Series
Rechargeable Battery
(Li-ion)
Rechargeable Battery
(Li-ion)
Nominal
Dimensions
Voltage
21700 3.6V/3.7V
21700 3.7V
18650 3.7V
Usability
Recommended
Usable
Banned
√√
√
×
