- Page 1 RGB SERIES RGB-CP425-PIX POCKET ON-CAMERA RGB LED WITH PIXEL EFFECTS USER MANUAL...
- Page 2 THANK YOU FOR CHOOSING GENARAY Genaray’s RGB-CP425-PIX is the latest addition to Genaray’s RGB series of LED lights. This versatile on-camera light provides you with full CCT and RGB functionality with hue, saturation, and intensity control so you can dial up any imaginable color. Five operating modes let you accurately set color temperature, manually select any color from the 360°...
- Page 3 PRECAUTIONS CONTENTS INCLUDE · Light · Diffuser · Cable · Please read and follow these instructions. · Shoe-mount adapter · Tabletop tripod · Keep this product away from water and flammable gases or liquids. · Carry pouch · Use only the correct, recommended voltage.
- Page 4 Power switch PRODUCT OVERVIEW Selection rocker USB-C charging port 1/4-20 socket RGB-CP425-PIX Pocket On-Camera RGB LED with Pixel Effects - USER MANUAL...
- Page 5 OLED screen Heat sinks Mounting magnets RGB-CP425-PIX Pocket On-Camera RGB LED with Pixel Effects - USER MANUAL...
- Page 6 MOUNTING THE LIGHT MOUNTING TO A TRIPOD OR LIGHT STAND Screw the light onto a tripod or light stand’s 1/4-20 stud, and tighten until secure. MAGNETIC MOUNTING Press the back of the light to any metal surface. The built-in magnets will hold it in place.
- Page 7 POWERING THE LIGHT CHARGING THE LIGHT Turn on the light by moving the power WIRED CHARGING switch upwards to the ON position. Use the USB-C cable to charge the light The OLED screen continuously calculates from a powered computer port, or use a the remaining battery time with the plug adapter like the Xcellon Mighty Mini changing light functions, effects, and...
- Page 8 USER INTERFACE MODE SELECTION All the operating modes that are described below can be accessed from the light’s selection rocker or the Genaray RGB Series 3.4h app. The instructions below explain how 2950 to operate and edit the modes from the selection rocker.
- Page 9 CCT MODE HSI MODE 3.4h 3.4h 2950 180° CCT: Adjusts the color temperature from HSI: Adjusts the hue from 0° to 359° of the 2800 to 8000 K in 50 K increments. color wheel. INT: Adjusts the brightness from 0% to SAT: Controls the saturation of the hue from 100% in 1% increments.
- Page 10 GEL MODE LIST OF GELS 3.4h 1. Blue 15. 1/8 Straw BLUE 2. 3/4 Blue 16. 15 Blue 3. 1/2 Blue 17. 30 Blue 4. 1/3 Blue 18. 60 Blue GEL: Select one of the 48 industry-standard colored gels. 5. 1/4 Blue 19.
- Page 11 EFX MODE 3.4h 29. 15 Yellow 39. 60 Magenta 30. 30 Yellow 40. 90 Magenta 31. 60 Yellow 41. 15 Pink 32. 90 Yellow 42. 30 Pink Ten animated lighting effects are preloaded into the light and can be accessed from the 33.
- Page 12 3. Press the selection rocker to highlight Pulsing: A steady pulse of white light that the intensity, and turn the rocker to fades on and off. adjust the brightness. Explosion: Simulates the light from explosions with bursts of light that flash on EFFECTS and fade off.
- Page 13 Seven animated pixel effects can be INT (Intensity): Adjusts the brightness accessed from the selection rocker or from 0% to 100% in 1% increments. the Genaray RGB Series app. Editable TRANS: Transitions between two defined parameters vary in each effect. colors on a continuous loop.
- Page 14 0.5 to 2 seconds. CLR (Color)2: Sets color 2 from 0° to 360°. DLY (Delay): Sets the amount of time each pixel holds a selected color from CLR (Color)3: Sets color 3 from 0° to 0.02 to 2 seconds. 360°. DIR (Direction): Sets the direction of the CLR (Color)4: Sets color 4 from 0°...
- Page 15 CLR (Color)1: Sets the running color counterclockwise. from 0° to 360°. FLOW: Four user-defined colors, CCT, or no CLR (Color)2: Sets the background color color, flow one at a time into the next. from 0° to 360°. CLR (Color)1: Sets color 1 from 0° to INT (Intensity) 1: Adjusts the brightness 360°, 2800 to 8000 K, and BLK (no color).
- Page 16 FLAME: Simulates a fire or candlelight with INT (Intensity) 1: Adjusts the brightness one color over a background color. of CCT 1 from 0% to 100% in 1% increments. CLR (Color)1: Sets the flame color from 0° to 360°, 2800 to 8000 K, and BLK (no INT (Intensity) 2: Adjusts the brightness color).
- Page 17 SETTINGS MODE > M/S: Controls Master/Slave function 3.4h M: The master light will control the setting of all RGB-series lights set to the same group and light number S: The slave light’s settings will be controlled by the master light or the RGB Press the selection rocker to select the desired setting menu.
- Page 18 GENARAY RGB APP The Genaray RGB app can control the Dimmer: Sets the brightness of all Genaray RGB-series lights from up to connected RGB-series lights. 33 feet away. The RGB app expands the 2800–8000 K: Sets the color temperature for RGB-CP425-PIX’s capabilities with a wider...
- Page 19 Up button resumes the current effect and operation. settings. The app’s user-friendly interface Important: Changes or modifications to this offers more options and control over your product not authorized by Genaray could lights. void the electromagnetic compatibility Note (EMC) and wireless compliance and negate To achieve perfect synchronization with your authority to operate the product.
- Page 20 Remote Control Type: Bluetooth Light Intensity @3 ft.: 3200 K: 144 lx Mobile App Compatible: 4400 K: 145 lx Yes: iOS and Android 5600 K: 185 lx App Name: Genaray RGB Series RGB-CP425-PIX Pocket On-Camera RGB LED with Pixel Effects - USER MANUAL...
- Page 21 RECYCLING LITHIUM- ION BATTERIES Wireless Range : 33 ft. (10 m) Lithium-ion batteries are recyclable. You can help preserve the environment by returning Wireless Channels/Groups: 99 channels, your used rechargeable batteries to a 99 groups collection and recycling location near you. For information about recycling POWER rechargeable batteries, call the Call2Recycle...
- Page 22 ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
- Page 23 To obtain warranty coverage, contact the Genaray Customer Service Department to obtain a return merchandise authorization (“RMA”) number, and return the defective product to Genaray along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser’s own risk and expense.
