- Page 1 BLT-60 PORTABLE DAYLIGHT FOCUSING LED USER MANUAL...
- Page 2 The Genaray Torpedo is a great choice for photographers and videographers who need a powerful and focusable beam from a compact, portable source. This advanced light is perfect for events that are usually shot on location, such as weddings and BLT-60 meetings.
- Page 3 · Use only the correct, recommended voltage. · Do not attempt to disassemble or repair the equipment—doing so will void the warranty, and Genaray will not be responsible for any damage. BLT-60 USER MANUAL...
-
Page 4: Product Overview
Focusing ring Heat vents LED array PRODUCT OVERVIEW Locking knobs Yoke screw Locking Barndoors knobs 5/8 in. light stand receiver BLT-60 USER MANUAL... - Page 5 Battery terminals Battery slot 3-pin mini XLR Battery power input release button Filters (× 3) D-tap cable AC adapter and Diffusers (×2) Lens power cord BLT-60 USER MANUAL...
- Page 6 If you remove the lens for any reason, you can replace it by fitting it into the Torpedo with the textured side facing in toward the LED. BLT-60 USER MANUAL...
- Page 7 The 3-pin mini XLR connector should fit easily into the Torpedo’s power input. Using force to insert Note the connector can damage the pins. Make sure the pins are aligned, and reinsert the connector until it clicks into place. BLT-60 USER MANUAL...
- Page 8 1. Unscrew the barndoors from the focusing ring. 2. Place the filter or diffuser over the lens. It will fit into the lens’s beveled inner edge. 3. Replace the barndoors by screwing them onto the focusing ring. BLT-60 USER MANUAL...
-
Page 9: Recommended Accessory
Torpedo and lets you attach light-shaping 15° spot to a 75° flood. tools with Bowens-style S-mounts, such as softboxes, diffusers, and globes. Turn the focusing ring to adjust the beam angle to the desired width. BLT-60 USER MANUAL... -
Page 10: Product Specifications
Weight: 2.6 lb. (1.2 kg) ≥96 Dimming: 100% to 1% Tungsten Equivalent: 250 to 300 W Battery: NP-F type Pro/Cine with D-tap connection Working Voltage: AC: 100 to 240 V, 50/60 Hz DC: 7.4 to 36 V BLT-60 USER MANUAL... - Page 11 ONE-YEAR LIMITED WARRANTY This GENARAY product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
