Genaray PortaBright MLACDCB User Manual

100 w bi-color monolight
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MLACDCB
PortaBright
100 W BI-COLOR MONOLIGHT
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Genaray PortaBright MLACDCB

Summary of Contents for Genaray PortaBright MLACDCB

  • Page 1 MLACDCB PortaBright 100 W BI-COLOR MONOLIGHT USER MANUAL...
  • Page 2 For extra directionality or texture, the integrated Bowens accessory mount is compatible with a host of easy-to- attach accessories. The PortaBright is outfitted with Genaray’s 2.4 GHz Lightseeker remote system, which adds the capability of selecting between 16 channels and five groups. The...
  • Page 3 · Do not attempt to disassemble or there are no missing parts. repair the equipment—doing so will · All images are for illustrative purposes void the warranty, and Genaray will not only. be responsible for any damage. PortaBright 100 W Bi-Color Monolight - USER MANUAL...

  • Page 4: Product Overview

    Light Fixture - Front Bowens mount release button Bowens mount COB LED array PRODUCT OVERVIEW Umbrella locking screw Umbrella hole Light stand mount Tilt lock Locking knob Locking button 5/8 in. receiver PortaBright 100 W Bi-Color Monolight - USER MANUAL...
  • Page 5 Light Fixture - Back Battery status Channel indicator Group indicator Brightness Color temperature Display Dimming/Color adjustment Release button knob Group button 3-pin power socket Channel button Power switch PortaBright 100 W Bi-Color Monolight - USER MANUAL...
  • Page 6 Light Fixture - Top Battery contacts Battery compartment PortaBright 100 W Bi-Color Monolight - USER MANUAL...
  • Page 7 Battery - Top Reflector Battery release buttons Battery - Bottom Battery terminals Umbrella mount Power input PortaBright 100 W Bi-Color Monolight - USER MANUAL...

  • Page 8: Charging And Installing The Battery

    CHARGING AND CONTENTS INCLUDE INSTALLING THE BATTERY · Monolight fixture The PortaBright includes a multivoltage 100–240 V AC, 50/60 Hz charger for · Reflector the rechargeable Li-ion battery. · Battery 1. Plug the battery charger into the battery, · Battery charger and cable and plug the AC cable into an outlet.

  • Page 9: Preparing For Use

    When not in use, the battery loses approximately 3% to 14% of its charge 1. Loosen the locking knob. per month. Genaray recommends 2. Press the locking button, and recharging the battery every 2 to 3 set the PortaBright on the months, even if it’s not in use.
  • Page 10 3. Release the locking button, and ATTACHING THE REFLECTOR hold the PortaBright with one The PortaBright features an integrated hand while tightening the locking Bowens mount that accommodates most knob until the light is secure. Bowens-compatible accessories such as To adjust the angle of the light, loosen reflectors, softboxes, grids, and snoots.
  • Page 11 POWERING THE PORTABRIGHT To remove the reflector, push the Bowens- USING THE PORTABRIGHT mount release button and turn the reflector WITH AC POWER counterclockwise to slide it out of the mount. Connect the AC power adapter to the ATTACHING AN UMBRELLA PortaBright with the included 3-pin cable, and plug the power cable into an outlet.

  • Page 12: Operating The Light

    OPERATING THE LIGHT USING THE PORTABRIGHT SETTING THE BRIGHTNESS WITH BATTERY POWER When it’s powered on, the PortaBright defaults to brightness mode. Make sure the power switch is in the off position, and the fixture is Use the adjustment dial to change not plugged into a wall outlet.

  • Page 13: Selecting Channels

    the temperature and return to 2. Use the adjustment dial to select brightness mode. If the adjustment a channel from 1 to 16. dial isn’t pressed to set the color 3. Press the channel button to set the temperature, the PortaBright returns channel and return to brightness mode.

  • Page 14: Product Specifications

    PRODUCT SPECIFICATIONS LIGHT FIXTURE Expected Lamp Life: 50,000 hr. LED Chip Type: COB Dimensions: Length: 8.5 in. (21.6 cm) without reflector Output Power: 100 W Diameter: 4.75 in. (12.1 cm) without reflector Beam Angle: 120° without reflector Weight: 4.5 lb. (2 kg) with battery 45°...

  • Page 15: Remote Operation

    RECYCLING LITHIUM-ION BATTERIES REMOTE OPERATION Lithium-ion batteries are recyclable. You can help preserve the environment by returning Remote Control Type: 2.4 GHz your used rechargeable batteries to a collection and recycling location near you. Number of Channels: 16 For more information about recycling Number of Groups: 5 rechargeable batteries, call the Call2Recycle helpline at 1-877-723-1297,...

  • Page 16: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
