Networking
The PIXELATOR MINI can either be configured to be a DHCP or Static IP address.
DHCP: On power-up with DHCP enabled, the PIXELATOR MINI requests an IP address from the network's
DHCP server. If no response is received or no DHCP server is available, it defaults to 192.168.0.10 with a
netmask of 255.255.255.0. Use the assigned DHCP address for communication if provided.
Static IP: By default (out of the box) the Static IP address will be 192.168.0.10. If the PIXELATOR MINI has
DHCP disabled, the Static IP address given to the device will become the IP address to communicate with
the PIXELATOR MINI. The IP address will change from the default once it is modified in the web interface.
Please note down the Static IP address after setting.
Web Interface
The PIXELATOR MINI is configured via an intuitive web interface, accessible through any modern web
browser. For the best experience, we recommend using a Chromium-based browser such as Google Chrome.
Identified IP address: If you are aware of the PIXELATOR MINI's IP address (either DHCP or Static), then the
address can be typed directly into the web browsers URL field.
Unidentified IP address: If you are not aware of the PIXELATOR MINI's IP address (either DHCP or Static) the
following discovery methods can be used on a local network to discover devices:
ENTTEC EMU software for Windows and MacOS (support Mac OSX 10.13 or later), which will Discover

ENTTEC devices on the Local Area Network, displaying their IP addresses before opting to Configure the
device, opening the Web Interface.
An IP scanning software application (i.e. Angry IP Scanner) can be run on the local network to return a

list of active devices on a local network.
Devices can be discovered using Art Poll (i.e. DMX Workshop if set to use Art-Net).

The device default IP address 192.168.0.10 will be printed on the physical label on the product.

Note
As the PIXELATOR MINI is hosting a web server on the local network and does not feature an SSL

Certificate (used to secure online content), the web browser will display the 'Not secure' warning, this is
to be expected.
The eDMX protocols, controller, and configuration device must be on the same LAN and IP range as the

PIXELATOR MINI. For example, if the PIXELATOR MINI is at 192.168.0.10, set your computer to 192.168.0.20.
Ensure all devices share the same Subnet Mask for proper communication.
Top Menu
The top menu allows all the PIXELATOR MINI web pages to be accessed. Menu option is highlighted blue to
indicate which page the user is on.
The top right corner of the window features 2 installer-friendly buttons:
Dark Mode: User interface view option that presents content on a dark background.
Identify: This command on the webpage identifies pixels connected to a specific PIXELATOR MINI without
the need to provide control data. This offers a convenience check-up for correct wiring. Note: The timer
will not restart when pressed consecutively.
