Frequently Asked Questions
I'm unable to connect to the PIXELATOR MINI web interface.
Ensure that the PIXELATOR MINI and your computer are on the same subnet.
To troubleshoot:
1. Connect the PIXELATOR MINI directly to your computer using a Cat5 cable and power it on.
1. Give your computer a Static IP address (e.g.: 192.168.0.20).
2. Change computer Netmask to (255.255.255.0).
3. Open ENTTEC EMU software.
4. Once EMU finds the PIXELATOR MINI, you will be able to open the device webpage and configure it.
Factory Reset the device using the reset button if the above steps do not resolve the issue.
The PIXELATOR MINI's factory default resets the device to static IP address 192.168.0.10 and Netmask
255.255.255.0 with DHCP enabled.
When the PIXELATOR MINI has DHCP enabled but DHCP server is unavailable (e.g. the device is connected
to a computer without DHCP server), the IP address will fall back to 192.168.0.10 with netmask 255.255.255.0.
What if my LED strip protocol is not in drop down list? How to add new LED strip
protocol to PIXELATOR MINI?
The PIXELATOR MINI allows the user to choose a pixel output protocol even it is not found in the drop-down
list.
Visit the ENTTEC Website to view the 'Custom Protocol Creation Guide' document for more information
about the key criteria and the step-by-step guide.
