pELLEt StovES USER MANUAL
UK
LUISELLA 5.0
MADE
IN
ITALY
design & production
004282491 - REV000

Advertisement

loading
Need help?

Need help?

Do you have a question about the LUISELLA 5.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Extraflame LUISELLA 5.0

Summary of Contents for Extraflame LUISELLA 5.0

  • Page 1 StovES USER MANUAL LUISELLA 5.0 MADE ITALY design & production 004282491 - REV000...
  • Page 2 APPLY TECHNICAL DATA LABEL ENGLISH...
  • Page 3 WarNINGS ........................................5 SafEty ..........................................5 routINE MaINtENaNcE ....................................7 INStaLLatIoN ........................................8 PREPARATIONS FOR MAINTENANCE ........................................8 DEtaILS of LuISELLa 5.0 ..................................... 10 SPACERS ..................................................11 FuSE ....................................................11 StovE poSItIoNING ..................................... 12 NotE for corrEct opEratIoN ................................12 pELLEt HoppEr - prESSurISED cLoSurE ..............................12 pELLEtS aND LoaDING ....................................
  • Page 4 ATTENZIONE ! OpgElET! durANTE lA mOvImENTAZIONE dEllA mAcchINA, lET TIJdENS dE vErplAATSINg vAN dE mAchINE IN hET fArE pArTIcOlArE BIJZONdEr Op vOOr dE ONdErdElEN IN hET dETAIl! ATTENZIONE AI cOmpONENTI IN dETTAglIO! WArNINg! TÄhElEpANu! durINg ThE hANdlINg Of ThE mAchINE, pAy AccurA- mASINA TEISAldAmISE AJAl OlgE TE ATTENTION TO ThE cOmpONENTS IN dETAIl! ErITI ETTEvAATlIk ErAldATud kOmpONENTIdEgA!
  • Page 5 We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 6 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
  • Page 7 (STRONG WIND, FREEzING) SAFETY SYSTEMS MAY INTERVENE THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.
  • Page 8 InstallatIOn general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
  • Page 9 In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: Š they must be protected with grids, metal mesh, etc., but without reducing the net useful section; Š...
  • Page 10 5.0 Combustive air Access to combustion chamber Pellet hopper pressurised closure input Display Room air outlet Serial input On/Off Spacer Upper fumes exhaust Fuse Room sensor Rear fumes exhaust Power supply 230v ENGLISH...
  • Page 11 spACers There are two spacers located on the rear of the machine which determine the minimum distance any support behind the stove. The spacers must not be removed. fuse If the stove is not powered, have the condition of the fuse checked by a qualified technician. ENGLISH...
  • Page 12 stove positioning To ensure the stove works correctly, it should always be positioned so that it is perfectly level, using a spirit level. note for CorreCt operAtion The following indications must be respected for correct pellet stove operation: Pellet hopper lid Both during the functioning and when the stove is not in use, all the machine doors (pellet hopper, fire door, ash drawer) must always remain closed.
  • Page 13 PELLETS AND LOADING Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin.
  • Page 14 The Display DescripTion of Basic commanDs anD symBols ON/OFF BUTTON INCREASE SET POWER DECREASE SET POWER INCREASE SET THERMOSTAT DECREASE SET THERMOSTAT Display icons key Indicates the presence of an alarm. On: indicates the presence of an alarm. Off: indicates there are no alarms Flashing: fire door or pellet hopper open Indicates the set temperature status LED on: the stove is reaching the set temperature (room temperature still lower than set temperature)
  • Page 15 General menu ON/OFF BUTTON - EXIT MENU SCROLL UP - CONFIRM SCROLL DOWN PRESS AND HOLD TO ACCESS MENU - ACCESS SELECTED MENU - INCREASE VALUE DECREASE VALUE ABiL (Ventilation) (Enabling) (Speed) EASY (Pellet calibration) CrNO ABiL (Chrono) (Enable) prg1 (PROGRAMMING 1) dATE prg2...
  • Page 16 remoTe conTrol When using the remote control, you can regulate the heating power, room temperature required and switch the device on/off. on/off Prolonged pressure turns the stove on or off. power increase Increases operating power power Decrease Decreases operating power T°...
  • Page 17 commissioninG seTTinGs Once the power cable at the back of the generator has been connected, move the switch, also located on the back, to (I). The switch at the back of the generator powers the generator board. The generator remains off and an initial screen appears on the panel, displaying OFF. dATE (DaTe) This menu allows the date to be set.
  • Page 18 operaTion anD loGic iGniTion Once the points listed previously have been checked, press key 1 for three seconds to ignite the stove. There are 15 minutes available to detect the presence of the flame during the ignition phase. When the control temperature is reached, stove interrupts the ignition phase and switches to PREPARATION.
  • Page 19 iT is forBiDDen To use The appliance wiThouT The flame GuarD (a). removal will compromise The safeTy of The proDucT anD resulT in The immeDiaTe nullificaTion of The warranTy perioD. in The evenT of wear or DeTerioraTion, ask The afTer-sales service To replace The parT (replacemenT Does noT fall wiThin The proDucT warranTy as The parT is suBjecT To wear).
  • Page 20 sTaT (sTaTus) references reserved for the technician crno (chrono) This function allows the stove's ignition and switch-off to be automatically programmed. The factory setting for CHRONO is off. The chrono allows the programming of 4 time slots within a day, which can be used every day of the week. ignition and switch-off times can be set for each time slot, along with the specific days of application for the programmed time slot, the desired temperature and power setting.
  • Page 21 CrNO > ABiL Enables/disables all the set chrono prg1 > ABiL On/Off Enabling/disabling PRG 1 STrT OFF-00:00-23:50 PRG1 start time STOp OFF-00:00-23:50 PRG1 stop time dAY1...dAY7 On/off Enabling/disabling days for PRG1 TEmp LOU - 07- 40 °C - HOT Set thermostat PRG1 pOW.
  • Page 22 EXAmpLE Of ChrONO OVErLAppiNg TimE/SLOTS Time slot 02:00 08:00 16:30 23:00 Power 02:00 08:00 16:30 23:00 Set temperature 22°C 18°C 02:00 08:00 16:30 23:00 start 02:00 Time slot 1 power 3 - set temp 22°C stop 23:00 start 08:00 Time slot 2 power 1 - set temp 18°C stop 16:30 stove operation...
  • Page 23 seT (seTTinGs) Š dATE Š dAY Š TimE SEE CHAPTER: COMMISSIONING SETTINGS. Š LNg Š C-f sTBy (sTanD-By) The stand-by function is used if the stove needs to be turned off immediately instead of a power modulation. CONTROLS PROCEDURE Š Press and hold key 4. Š...
  • Page 24 clea (rouTine cleaninG) This function facilitates the normal cleaning of the combustion chamber by activating the flue gas fan. With the stove cold and switched "Off", activate the CLEA function. The message "dO ThE CLEANiNg" appears. Open the fire door and, using the poker supplied, clean the combustion chamber. When cleaning is complete, close the door and end the function by pressing key 1 ON/OFF.
  • Page 25 aDDiTional funcTions key lock The menu allows the user to lock the display keys (like with mobile phones). Using the key lock after Activation: To lock the keyboard, press keys 1 and 5 at the same time until the following appears: "keys locked" To unlock the keyboard, press keys 1 and 5 at the same time until the following appears: "keys unlocked"...
  • Page 26 When the tank is completely empty, disconnect the power cable of the generator and remove the residues first (dust, chippings, etc.) from the empty tank, and then fill it. to find out whErE your nEarEst sErvicE cEntrE is, contact your dEalEr or go to thE wEbsitE: www.lanordica-EXtraflamE.com ENGLISH...
  • Page 27 every day burn pot and Combustion Chamber: Š Vacuum the residue in the burn pot Š Remove the burn pot completely from the relevant compartment; Š Vacuum the ash from the burn pot slot, ignition plug pipe holder and combustion chamber. Š...
  • Page 28 every 30 days Š Remove the cast-iron wall by tilting it (C). Cleaning the tube heat exChanger Š Once the central cast iron wall has been removed, clean the tube heat exchanger (D). Š Vacuum the residue in the burn pot Š...
  • Page 29 the gaskets for the pellet hopper, burn pot and fire door ensure that the stove works properly. it is neCessary to periodiCally CheCk them; if they seem to be worn or damaged, they must be replaCed immediately. these operations must be Carried out by a qualified teChniCian. a Clean burn pot guarantees CorreCt operation! by making sure the burn pot and its holes are always Clean from any Combustion residue, exCellent Combustion by the generator is...
  • Page 30 Routine maintenance must be performed at least once a year. to find out whErE your nEarEst sErvicE cEntrE is, contact your dEalEr or go to thE wEbsitE: www.lanordica-EXtraflamE.com ENGLISH...
  • Page 31 every year (teChniCal) heat exChanger ENGLISH...
  • Page 32 routine maintenanCe THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone or gasket in the points indicated. Gaskets, pellet hopper and door (replace them and apply silicone where required) Combustion chamber and heat exchanger (full cleaning) including ignition-plug pipe Hopper (complete emptying and cleaning) and check gasket.
  • Page 33 routine maintenanCe THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES ONLY. Fumes motor (disassembly and cleaning and fumes and "T" pipes), new silicone or gasket in the points indicated. Gaskets, pellet hopper and door (replace them and apply silicone where required) Combustion chamber and heat exchanger (full cleaning) including ignition-plug pipe Hopper (complete emptying and cleaning) and check gasket.
  • Page 34 DISPLAYS DISPLAY REASON Generator off START The start-up phase is in progress PELLET LOADING Continuous pellet loading is in progress during the ignition phase IGNITION The ignition phase is in progress PREPARATION The preparation phase is in progress WORk The normal work phase is in progress MODULATION The generator is working at minimum fINAL cLEANING...
  • Page 35 Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.
  • Page 36 CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products. 18/12/2023 004282491-000 MAN.UT. LUISELLA 5.0 [E224]...
