We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
Page 6
RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
(STRONG WIND, FREEzING) SAFETY SYSTEMS MAY INTERVENE THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.
InstallatIOn general The flue gas exhaust and hydraulic connections must be carried out by qualified personnel who must issue installation conformity documentation compliant with national standards. The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity, supplied with: 1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);...
Page 9
In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or ventilation opening. The air inlets must meet the following requirements: they must be protected with grids, metal mesh, etc., but without reducing the net useful section; ...
Hermetically sealed installation The generator is a fully sealed product with respect to the environment in which it is installed. This means that it is ideal for passive houses because it does not take air in from within the house. combustion air To ensure the stove remains hermetically sealed, the connection pipe for the combustion air must be directly connected to the exterior, using special pipes and sealed connectors.
Standards in force, national, regional and municipal, as well as these instructions. For Italy, installation must be carried out by professionally qualified staff (Ministerial Decree dated 22.01.08 n°37). Extraflame S.p.A. declines all responsibility for damage to objects and/or persons caused by the system. TYPE OF SYSTEM ...
DISTANCES OF SAFETY DEVICES ACCORDINg TO THE STANDARD The temperature safety sensors must be in place on the machine at a distance no greater than 30 cm from the flow connection. Whenever the generators lack a device, those missing can be installed on the generator flow pipe, within a distance no greater than 1 m from the machine. COMMISSIONINg CHECkS Before connecting the boiler: a) wash all system piping thoroughly in order to remove any residues which might compromise the correct functioning of certain system...
FIANDRA IDRO evO DetAIls Room air outlet Heat exchanger scrapers Door handle Heat exchanger scrapers Access to the ash Pellet hopper drawer Room air outlet Radio/emergency card Fumes exhaust On/OFF Fuse Power supply 230v Combustive air input HyDRAulIc INstAllAtION 3 bar safety drain...
FeAtuRes Water content of the thermo-product heat exchanger (l) volume of expansion vessel integrated into thermo-product (l) 3 bar safety valve integrated into the thermo-product Minimum and maximum pressure switch integrated into the thermo-product Pump integrated into the thermo-product Pump max. head (m) Envision any inTEgraTivE Expansion vEssEl on ThE Basis of ThE sysTEm WaTEr conTEnT.
stOve pOsItIONINg For correct product functioning, it is recommended to position it in a way that it is perfectly level, with the aid of a spirit level. NOte FOR cORRect OpeRAtION Pellet hopper lid The following indications must be respected for correct pellet stove operation: Both during the functioning and when the stove is not in use, all the machine doors (pellet hopper, fire door, ash drawer) must...
Pellets and feeding Pellets are made by subjecting wood shavings i.e. the rejects of pure wood (without paint) sawmill, carpenter products and products from other activities connected to working and transforming wood, to very high pressures. This type of fuel is fully ecological as no glues are used to hold it together. In fact, the compactness of the pellets is guaranteed over time by a natural substance that is found in wood: wood coal.
Radio/emeRgency caRd The stove is fitted with an emergency radio card allowing the basic operation of the stove in the event the LCD handheld remote is damaged or malfunctions. Not in use The functions that can be managed from the emergency card are: Power supply presence Power decrease LED off: stove off...
radIO cOntrOl devIce cOnFIGUratIOn RAdIo conTRol devIce codIng pRoceduRe: 1. disconnect the power supply to the stove. 2. press the keys at the same time until the UNIT selection screen appears. 3. using keys select the new UNIT' . 4. power the stove. Within 10 seconds (the led on the emergency module will flash) confirm the selected unit by pressing on the radio control device.
radIO cOntrOl devIce FeatUres The radio control device is fitted with an lcd backlit display. The display remains lit for 5 seconds. After a certain period of time, in order to minimise battery consumption, the display turns off (sleeP mode). ...
dIsplay screen wiTh venTilaTion noT enaBled Stby active chrono active Battery low power 1-5^ Time Water temperature (H2o) detected in the boiler Set H2o temperature set display text screen wiTh venTilaTion enaBled Stby active chrono active Battery low power 1-5^ Time Water temperature (H2o) Temperature detected in...
General menU FUncTion FUncTion Scroll through parameters Back - exit key Modify settings on - off key Access menu key venTilaTion enaBlinG sPeed easy seTUP seT TherMosTaT chrono enaBlinG PrG1 PrG2 seTTinGs daTe-TiMe PrG3 lanGUaGe PrG4 disPlay sTand By FirsT load oUTleT air cleaninG *sTove sTaTUs...
FIrst IGnItIOn settInGs once the power cable at the back of the generator has been connected, move the switch, also located on the back, to (i). The switch at the back of the generator powers the generator board. The generator remains off and an initial screen appears on the panel, displaying oFF. daTe-TiMe This menu allows the date and time to be set.
OperatIOn and lOGIc iGniTion once the previously listed points have been checked, press key for three seconds to ignite the stove. 15 minutes are available for the ignition phase. After ignition and after reaching the control temperature, the stove interrupts the ignition phase and switches to pRepARATIon.
addItIOnal tHermOstat n.B. : InstallatIOn mUst Be perFOrmed By an aUtHOrIsed tecHnIcIan It is possible to control the temperature of a room adjacent to the room where the stove is positioned; simply connect a thermostat following the procedure described in the following section (it is advisable to place the optional mechanical thermostat at a height off the ground equal to 1.50 m).
ventIlatIOn This menu allows to enable or disable the operation of the tangential motor and to adjust the speed (-2, -1, 0, +1, +2) of the front fan. The seT TherMosTaT allows to set the room temperature to be reached (front ventilation must be active). once the temperature set in seT TeMPeraTUre has been reached, the ventilation will turn oFF and then it will turn back on when required.
cHrOnO This function allows stove ignition and switch-off to be automatically programmed. The factory setting for cHRono is off. The chrono allows the programming of 4 time slots per day, which can be used every day of the week. For each time slot, it is possible to set ignition and switch-off times, specific days of application, desired temperature and set power.
Page 27
eXaMPle oF chrono overlaPPinG TiMes/sloTs TIMe SloT 02:00 08:00 16:30 23:00 SeT poWeR 02:00 08:00 16:30 23:00 SeT H2o 72° 68° 02:00 08:00 16:30 23:00 Start 02:00 Time slot 1 power 3 - SeT H2o 72°c Stop 23:00 Start 08:00 Time slot 2 power 1 - SeT H2o 68°c Stop 16:30...
settInGs • date-tIme • lanGUaGe See chapter: firSt ignition SettingS • set deGrees dIsplay The "disPlay" menu allows: Adjustment of display contrast. Activation/deactivation of backlight. enabling/disabling of acoustic signal. Setting of the timer to turn off the display backlight. ...
reset Allows the user to reset all editable values to the default values. To set: OK > SeTTINgS > reSeT. easy cOntrOl The function allows for two values to be set: oFF (disabled - factory default) on (enabled) Activation (easy conTrol = on) is recommended in the event that there is an excessive formation of combustion residues in the flue during operation at reduced power (see Flue eXHAuST chapter).
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM CLEANING AND MAINTENANCE ALWAYS FOLLOW THE INSTRUCTIONS IN COMPLETE SAFETY! For all operations, except for routine cleaning, make sure that the power cord plug is disconnected as the generator may have been programmed to turn on.
Page 31
COMbUSTION CHAMbER By means of a mechanical system, the burn pot is cleaned automatically at preset intervals. It is however advisable to remove any residues by using a vacuum cleaner. Suck the ash deposited between the partition and the fire holder (1). ...
A CLEAN bURN POT GUARANTEES CORRECT OPERATION! bY kEEPING THE bURN POT AND ITS HOLES CONSTANTLY CLEAN AND FREE OF COMbUSTION RESIDUE, EXCELLENT COMbUSTION IS GUARANTEED OVER TIME, THUS PREVENTING ANY GENERATOR MALFUNCTIONS THAT MAY REQUIRE TECHNICAL ASSISTANCE. THE “EASY SETUP” FUNCTION IN THE USER MENU CAN bE USED TO ADAPT COMbUSTION ACCORDING TO THE NEEDS DESCRIbED.
Page 33
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE iMAgES ARE foR illUSTRATiVE PURPoSES. Fumes motor (disassembly and cleaning and fumes pipe and "T"), new silicone in the provided points Gaskets, pellet hopper, inspections, ash drawer and door (replace and apply silicone where indicated) Combustion chamber and heat exchanger (full cleaning) including ignition plug pipe Hopper (complete emptying and cleaning).
Fumes motor fault Contact after-sales centre faUlT fUMes pRoBe Fumes probe fault. Contact after-sales centre if there is an additional system data-sheet TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM ENGLISH...
Page 35
Pump blocked. Electronic module damaged Pump blocked. floW pWM alaRM Liquid with high density. Contact after-sales centre Pipe obstructed. if there is an additional system data-sheet TO FIND OUT WHICH IS YOUR NEAREST AFTER-SALES CENTRE, CONTACT YOUR DEALER OR VISIT THE WEBSITE WWW.LANORDICA-EXTRAFLAME.COM ENGLISH...
Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.
Page 40
CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products. 25/08/2021 004280684-000 MAN.UT. FIANDRA IDRO EVO...
