Hyundai power products HYMT5200X-1 Instruction Manual

5-in-1 petrol multi-tool
Hide thumbs

Advertisement

Quick Links

Download this manual
5-IN-1 PETROL MULTI-TOOL
HYMT5200X-1
Instruction Manual
WARNING: Read the instructions carefully before use.
Iss:Nov/24

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYMT5200X-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai power products HYMT5200X-1

Summary of Contents for Hyundai power products HYMT5200X-1

  • Page 1 5-IN-1 PETROL MULTI-TOOL HYMT5200X-1 Instruction Manual WARNING: Read the instructions carefully before use. Iss:Nov/24...
  • Page 2 Contents Operation……………………….……….34-43 Introduction……..……………………………3 Connecting The Extension Boom………34 Using The Extension Boom……………….34 Safety Information…..…………………..4-13 Using The Grass Trimmer………………….35 Understand Your Machine.…...…………...4 Using The Pole Saw…………………..36-37 Personal Safety...…….……………………4-5 Using The Cutting Blade………………….38 Inspect Your Machine……………………...5 Using The Hedge Trimmer………………..39 Work Area…….……………………………..5 Re-Filling The Trimmer Line…………...40-41 During Use….………………………………6-9 Pole Saw Safety...…..……………………10 Starting/Stopping Procedure………..42-44...
  • Page 3 THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product.
  • Page 4 Safety Information Understand Your Machine • WARNING! You must read these instructions carefully before operating the machine. Make sure that you are familiar with the controls and properly operate the machine. You must learn how to stop the machine quickly. If you do not follow the warnings and instructions, it may result in fire and/or serious injury.
  • Page 5 Safety Information Personal Safety (Continued) • Do not touch parts that might be hot from operation. Allow parts to cool before attempting to maintain, adjust, or service. • Do not overreach. Keep proper footing and balance at all times. This enables better control of the machine in unexpected situations.
  • Page 6 Safety Information Work Area • You must only work in daylight or with good artificial light in good visibility conditions. Do not work at night, at times of heavy fog, or at any other times when your field of vision might be limited and it would be difficult to gain a clear view of the area.
  • Page 7 Safety Information During Use • Always hold the unit with both hands when operating. Keep a firm grip on the handlebars • Do not operate the machine in confined areas where there may be a risk of crushing the operator between the machine and another object. •...
  • Page 8 Safety Information During Use (Continued) Be aware of your environment and all possible hazards that you may be unable to hear while using the machine. • Keep an eye not only on the branches being cut, but also on fallen material, to avoid tripping.
  • Page 9 Safety Information During Use (Continued) • The cutting blade flings objects and soil with great force. These can blind or cause other injuries. Wear eye, face and leg protection. Always remove objects from the work area before using the cutting blade. •...
  • Page 10 Safety Information Pole Saw Safety • To avoid injuries due to falling branches, do not stand under the branches that you want to cut off. Be aware of branches that may spring back and cause injuries. Work at an angle of approximately 60°. •...
  • Page 11 Safety Information Engine Safety • This machine is equipped with an internal combustion engine. Do not use on, or near, forest-covered or brush-covered land unless the exhaust system is equipped with a spark arrester meeting applicable local, state, or federal laws. •...
  • Page 12 Safety Information Carbon Monoxide DANGER Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside a confined space, such as but not limited to a house, garage, vehicle, boat or tent.
  • Page 13 Safety Information Fuel Safety CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF REACH OF CHILDREN. General Safety Do not smoke each time fuel is handled. • ALWAYS avoid inhaling fumes. •...
  • Page 14 Safety Information Fueling/De-Fueling • ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel to the fuel container – only outdoors. Do not smoke during this and each time fuel is handled. •...
  • Page 15 Safety Information Vibrations (Where Applicable) • Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate temperature, causing numbness and heat sensations and may cause nerve damage and circulatory tissue death.
  • Page 16 Safety Information Intended Use The HYMT5200X-1 is a petrol powered multi-tool from HYUNDAI and is powered by a 52cc 2-stroke petrol engine. The multi-tool is manufactured according to the latest safety requirements. Every precaution is only effective when it is followed exactly.
  • Page 17 Safety Information Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc.
  • Page 18 Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgement.
  • Page 19 Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgement.
  • Page 20 Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgement.
  • Page 21 Unboxing WARNING : Unboxing and assembling the machine should be done on a flat, surface with plenty of room. Disposal of the packaging should be done in accordance with the local regulations in force. WARNING : Some of the packaging material may be harmful to children.
  • Page 22 In The Box *Not To Scale www.hyundaipowerproducts.co.uk...
  • Page 23 Features Engine Guard Brush Cutter 3 Tooth Blade The brush cutter will allow you to cut through thicker and tougher foliage. Handle Grass Trimmer Head The Grass trimmer will enable a quick and efficient cut through overgrown grass, and to trim the edges of your lawn. Pole Saw The 295mm cutting bar is suitable for all but the biggest of logs and branches.
  • Page 24 Assembly Assembly Overview There are 6 steps to the assembly: STEP 1. Attach The Engine Unit Handle STEP 2. Cutting Blade Attachment STEP 3. Lower Guard Assembly STEP 4. Grass Trimmer Head Assembly STEP 5. Pole Saw Attachment Assembly STEP 6. Using The Harness STEP 1 : Attach Engine Unit Handle 1.
  • Page 25 Assembly STEP 1 : Attach Engine Unit Handle (Continued) 4. Place and secure the handle onto the moulding. The handle MUST be facing inwards towards the engine unit. 5. Attach both halves of the moulding back together and tighten the bolts to secure the handle.
  • Page 26 Assembly STEP 2 : Cutting Blade Attachment (Continued) 3. Fit the Cutting blade by placing the blade face down over the central register. The Hyundai marking on the blade should be out of sight and facing towards the head. IMPORTANT!: Ensure the blade sits flush on the head. Extreme vibration will occur if it is not mounted correctly.
  • Page 27 Assembly STEP 3 : Lower Guard Assembly 1. Remove the two bolts that are already in place in the guard. 2. Line up the guard to the holes located on the bracket, in readiness to fasten the bolts. Use the 5mm Allen key to tighten the bolts and secure the guard.
  • Page 28 Assembly STEP 5 : Pole Saw Attachment Assembly WARNING: The teeth on the chain are very sharp. It is strongly advised that thick gloves are worn when handling the chain. 1. Remove the two bolts that are already in place in the guard. 2.
  • Page 29 Assembly STEP 5 : Pole Saw Attachment Assembly (Continued) 4. Continue to secure the bar to the chain by feeding teeth around the circumference of the bar until correctly positioned. 5. Refit the bar cover back into position and secure the nut onto the thread.
  • Page 30 Assembly STEP 5 : Pole Saw Attachment Assembly (Continued) IMPORTANT: During the Pole saw attachment’s initial use, the chain’s tension may slacken. Check the chain periodically to ensure the tension is at its optimum. Adjust accordingly if the chain has lost its tension.
  • Page 31 Preparation – Before Each Use YOU MUST read and understand the full safety instruction manual before starting the machine. CAUTION – For OUTDOOR use ONLY. Petrol machines produce monoxide – poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly flammable, always handle with extreme care and in a well ventilated area.
  • Page 32 Preparation – Fuel And Oil IMPORTANT: This is a 2-stroke stroke engine and will need 2 stroke oil mixed with the unleaded petrol. The mix is 40 parts petrol to 1 part oil. (40:1). i.e. 1 litre of petrol requires 25ml of (semi-synthetic) 2 stroke oil.
  • Page 33 Fuel Safety CAUTION: Never remove the tank filler cap or top up the petrol tank while the engine is running or hot. Allow time for the engine and the exhaust components to cool down before refuelling. For your safety, please refer to the following: •...
  • Page 34 Operation Connecting The Extension Boom 1. Remove the rubber cap from the end of the shaft. 2. Insert the boom into the end of the engine unit shaft. Ensure the rectangular slot with the square plastic piece is facing the bottom when inserting the boom into the end of the shaft.
  • Page 35 Operation Using The Grass Trimmer 1. To extend strimmer line from head, with the head spinning, simply bump the head down onto the ground and the line will automatically be fed out from the spool inside the head. 2. Do not press strimmer head hard onto the ground when using the trimmer.
  • Page 36 Operation Using The Pole Saw CAUTION: Use extreme care whilst using this attachment. NEVER operate around children and pets. CAUTION: Be aware of overhead power/telephone wires. 1. Always check the tension of the cutting chain before use. 2. This tool is only for pruning trees. Do not cut wood lying on the ground.
  • Page 37 Operation Using The Pole Saw – Preventing Kickback 1. Kickback happens when the tip of the blade catches in the wood you are cutting. This causes the blade to jerk and you may loose control. NEVER cut using the top part of the tip of the blade. 2.
  • Page 38 Operation Using The Cutting Blade CAUTION: Use extreme care when using this tool. 1.Always firmly grip the handle with both hands when using the cutting blade attachment. 2. Keep children and pets at least 15m away when using. 3. The blade can fling stones and debris with great force. Always use face, leg and ear protection.
  • Page 39 Operation Using The Hedge Trimmer CAUTION: Use extreme care whilst operating this attachment. Avoid operating around children and pets. 1. Always use eye and ear protection. 2. Always switch off the engine before performing any maintenance or adjustments to the cutting blades. 3.
  • Page 40 Operation Re-Filling The Trimmer Line NOTE! This machine requires 2.4mm thick Nylon Trimmer Line 1. Rotate the blue centre piece to align the arrow mark with the holes. 2. Check that the two holes are aligned. 3. Using 4m of 2.4mm nylon trimmer line, pass it through the two holes until you have 2m each side.
  • Page 41 Starting/Stopping Procedure NOTE: This machine is shipped without fuel and oil and MUST be filled before use. Failure to do so may cause damage to the engine that will not be covered by warranty. Cold Start 1. Squeeze the primer bulb at least 6 times until fuel is being moved through the fuel line.
  • Page 42 Starting/Stopping Procedure Cold Start (Continued) 4. With your left hand holding down the engine, firmly pull the start cord with your right hand. Repeat until the engine starts, or attempts to start. 5. Once the engine starts, gently squeeze the throttle to disengage the choke.
  • Page 43 Starting/Stopping Procedure Warm Start – when the appliance has been turned off for less than 10 minutes. Start the machine with the choke in the down position. 1. Slide the On/Off switch back towards the engine. Place left hand on top of engine. 2.
  • Page 44 Maintenance Maintenance Safety IMPORTANT - Routine and accurate maintenance is essential for maintaining original machine safety and performance levels. WARNING - Before cleaning or doing maintenance work, you need to stop the engine, disconnect the spark plug cable and read the relevant instructions.
  • Page 45 Maintenance Cleaning CAUTION – DO NOT use a hose pipe or pressure washer to clean the engine. Water can damage the engine and/or contaminate the fuel system. NOTE – Engine must be switched off and spark plug lead disconnected. General Cleaning •...
  • Page 46 Maintenance Storage – Where To Store Store in a cool, dry place away from sources of ignition and varying changes in temperature. DO NOT stack other items on top of the machine when in storage. The protectors must be fitted for transport and storage. Store the machine in a safe place, out of the reach of children or anyone who is not familiar with operation.
  • Page 47 Maintenance Long Term Storage (Continued) 4. Follow the maintenance section and check, service or replace serviceable items if required. Visually inspect the machine and replace or repair any worn parts. Check the blade and sharpen or replace if necessary. 5. Remove the spark plug. Add 1 teaspoon of 2-stroke oil to the combustion chamber.
  • Page 48 Maintenance Pole Saw Oil 1. You can adjust the amount of oil that is applied to the chain by turning the screw located underneath the chain guard cover. It has 3 positions. The middle is the factory set position. Push and click anticlockwise for more oil.
  • Page 49 Maintenance Air Filter CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine performance and efficiency. This machine uses an Oil Soaked foam air filter. This type of filter can be removed and cleaned. If cleaned always remember to re-soak the air filter in oil.
  • Page 50 Maintenance Spark Plug For good performance, the spark plug must be properly gapped and free of deposits. 1. You MUST allow the engine to cool down before carrying out any maintenance. 2. Always use the correct spark plug. 3. Pull off the spark plug connector. 4.
  • Page 51 Maintenance Lubricating The Gears 1. Add liquid gear grease after every 20 hours of operation (approx. 10g) to lubricate the angle gear. 2. To do this, undo the screw to press the gear grease into the gear housing. 3. After filling the gearbox, close the lubrication hole with the screw. www.hyundaipowerproducts.co.uk...
  • Page 52 Maintenance Lubricating The Saw Chain 1. Remove the oil filler cap. 2. Fill oil tank with organic chain oil. 3. The chain lubrication can be increased or decreased using the oil adjusting screw. 4. Press and then turn the oil adjusting screw clockwise to decrease the chain lubrication.
  • Page 53 Maintenance Tightening And Checking The Saw Chain WARNING – Wear protective gloves. There is a danger of injury from the sharp cutting teeth. A new saw chain stretches and must be tightened more frequently. 1. First loosen the cover retaining nut to release the bar. 2.
  • Page 54 Maintenance The figures given here are based on normal operating conditions. In the event of more difficult conditions, such as strong dust generation and longer daily operating hours, the given intervals are to be reduced accordingly. Pole Saw Maintenance Schedule Appliance Before Starting Weekly...
  • Page 55 Troubleshooting Engine Unit Troubleshooting Problem Possible Cause Possible Solution The engine does not Incorrect start-up Follow the start start. process. procedure. The engine starts but 1. Incorrect 1. Move the choke does not run at full adjustment of the lever to the upper power.
  • Page 56 Technical Data Engine Specifications Engine Type 2-Stroke Engine, Air-Cooled Engine Output (Max) 1.45kW / 2.0hp Engine Size 51.7cc Engine Idle Speed 3000rpm Engine Speed (Max.) With 3-Section Cutting Blade: 6900rpm With Grass Trimmer: 8700rpm With Chainsaw: 9200rpm With Hedge Trimmer: 1550rpm Max.
  • Page 57 Technical Data Engine Specifications Engine Type 2-Stroke Engine, Air-Cooled Engine Output (Max) 1.45kW / 2.0hp Engine Size 51.7cc Engine Idle Speed 3000rpm Engine Speed (Max.) With 3-Section Cutting Blade: 6900rpm With Grass Trimmer: 8700rpm With Chainsaw: 9200rpm With Hedge Trimmer: 1550rpm Max.
  • Page 58 Technical Data Pole Saw Specifications Oil Tank Recommended Fill Level 140cm Cut Length Approx. 260mm Blade 10 inch Saw Chain 10 inch Brush Cutter Specifications Metal Blade Cutting Diameter 255mm Grass Trimmer Specifications Nylon Line Cutting Circle 430mm Nylon Line Length Nylon Line Diameter 2.4mm www.hyundaipowerproducts.co.uk...
  • Page 59 Technical Data Noise Information Hedge Pole Saw Brush Cutter Grass Trimmer Trimmer Sound 99.47dB(A) 99.5 93.24 94.74 Pressure Level LpA Uncertainty 2.5dB Sound 110.05dB(A) 111.54 105.52 105.62 Power Level Guaranteed 114dB(A) Sound Power Level Uncertainty 2.5dB Vibration Information Hedge Pole Saw Brush Grass Trimmer...
  • Page 60 Recycling & Disposal Recycling & Disposal We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site.
  • Page 61 Importer and Authorised Representative Genpower Ltd Isaac Way, Pembroke Dock, SA72 4RW Country of Origin: China Description: Petrol Multi-tool SKU Code: HYMT5200X-1 Date of Issue: 16/12/2019 Regulations and Directives of Compliance 2006/42/EC The Machine Directive • 2014/30/EU Annex ll Electromagnetic Compatibility Directive •...
  • Page 62 Notes www.hyundaipowerproducts.co.uk...
