Summary of Contents for Hyundai power products HMT12V2A
-
Page 2: Table Of Contents
CONTENTS 1. INTENDED USE....................3 2. SAFETY INSTRUCTIONS................3 3. EXPLANATION OF SYMBOLS..............7 4. YOUR PRODUCT..................8 5. TECHNICAL DETAILS.................9 6. BEFORE USE.....................10 7. OPERATION....................11 8. CLEANING AND MAINTENANCE……………………………………………13 9. STORAGE AND TRANSPORTATION............13 10. TROUBLESHOOTING................13 11. DISPOSAL....................14 12. DECLARATION OF CONFORMITY............15 13. WARRANTY....................16 14. -
Page 3: Intended Use
1. INTENDED USE This tool is intended to be used for the sanding of little surfaces, corners, edges, for stripping, cutting little pieces in metal, wood or plastics. Do not use this tool for others purposes. Misuse will create accidents and injuries. It is intended only for a domestic use. - Page 4 e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts.
- Page 5 6. Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
- Page 6 SAFETY INSTRUCTIONS FOR CHARGER 1. This charger can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the charger in the safe way and understand the hazards involved.
-
Page 7: Explanation Of Symbols
Warning! During operating, the product generates an electromagnetic field which, under certain circumstances, may impair the functionality of active or passive medical implants. To reduce the risk of serious or lethal injuries, we recommend that persons with medical implants consult their doctor and the manufacturer of their medical implant before operating the electric tool. -
Page 8: Your Product
4. YOUR PRODUCT Fig A Fig B Fig D Fig C Fig E Fig F 1. Tool release lever 9. Tool holder 2. ON/OFF switch 10. Speed adjustment wheel 3. Battery release button 11. Battery level indication LED 4. Dust collector unit 12. -
Page 9: Technical Data
5. TECHNICAL DATA Rated voltage 12V d.c. Rated no-load speed n 5000-18000/min Oscillation angle 3.2º Weight (without charger) 1.2kg Battery pack DC33 Type Li-ion Rated voltage 12V d.c. Capacity 2.0Ah (24Wh) Battery charger DC122400 Rated input 220-240V~, 50-60Hz Rated input Power Rated output 12V d.c. -
Page 10: Before Use
6. BEFORE USE Always disconnect the battery pack from the tool before making any adjustment or attaching any accessories. CHARGING THE BATTERY (FIG. C) IMPORTANT: The battery pack is not fully charged at the factory. Before attempting to charge them, thoroughly read all of the safety instructions. -
Page 11: Operation
CONNECTING A DUST EXTRACTION UNIT (FIG. F) Place the dust extraction unit (4) under the appliance and fix it into place on the appliance. Align the grooves on both sides of the dust extraction unit, and install downward, then turn clockwise to fix well the dust extraction unit. - Page 12 Materials: Tile adhesives, tile joints Application: Removing material residues, such as tile adhesive, when replacing damage tile Milling grout on wall and floor tiles HCS plunge saw blade (15) Materials: wood, plastic, gypsum (plaster) and other soft materials Application: Separation and plunge saw cuts Sawing close to edges, even in hard-to-reach areas, for example, sawing recesses in lightweight walls ...
-
Page 13: Cleaning And Maintenance
8. CLEANING & MAINTENANCE WARNING! Risk of injury. Always switch the appliance off and remove the battery pack before carrying out any work on the appliance. • Repair and servicing work not described in this manual should always be carried by our service center. -
Page 14: Disposal
Problem Possible cause Corrective action Product won’t start Battery pack discharged Recharge the battery Battery pack not inserted Insert the battery pack ON/OFF switch cannot be pressed Send to the service center for repair properly or defective Different charging The battery pack is only partly charged Re-charge the battery pack time The charger broke... -
Page 15: Declaration Of Conformity
BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux - France, declares that, Product: Cordless multi Tool Trade mark: HYUNDAI Model: HMT12V2A Serial number: 20210636843-20210639967 is in conformity with the essential requirements and other relevant provisions of the applicable European Directives, based on the application of European harmonized standards. -
Page 16: Warranty
13. WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. -
Page 17: Product Failure
14. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: • Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 18: Warranty Exclusions
15. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
