EGR ROLLTRAC RT040552E Installation Instructions Manual page 7

A
B
1
IMPORTANT: Make sure the fuses are not fitted before making connection.
Connect the vehicle harness branch (B) to vehicle body negative ground as shown and secure with M6 hex nut (35).
Connect the vehicle harness branch (A) to the positive terminal of the battery and secure with M6 hex nut (35).
Once it is positioned, secure in place using two cable ties as
2
Pull the vehicle harness from engine bay down to the floor behind the front left wheel. Direct it towards the rear of
the vehicle. Secure the vehicle harness to the vehicle loom in the two areas shown using cable ties.
ISSUE 1: 05/08/24
-- EGR Document ID#123932 v2
B
A
Page 7 of 34
2024-09-13 23:52:53
B
NEGATIVE TERMINAL
A
shown.
REAR
agramm --
35
35
BATTERY
POSITIVE TERMINAL
RT0403
