- Page 1 NI-9263 Getting Started 2022-07-06...
-
Page 2: Table Of Contents
NI-9263 Getting Started Contents Overview..............3 Safety Guidelines. -
Page 3: Overview
NI-9263 Getting Started Overview This document explains how to connect to the NI-9263. In this document, the NI-9263 with screw terminal and the NI-9263 with spring terminal are referred to inclusively as the NI-9263. Note Before you begin, read the NI-9263 Safety, Environmental, and Regulatory Information document on ni.com/manuals... -
Page 4: Safety Voltages
Safety Guidelines for Hazardous Locations The NI-9263 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 Gc and Ex nA IIC T4 Gc hazardous locations;... - Page 5 II 3G and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9263 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
-
Page 6: Electromagnetic Compatibility Guidelines
Furthermore, any changes or modifications to the product not expressly approved by National Instruments could void your authority to operate it under your local regulatory rules. Special Conditions for Marine Applications Some products are approved for marine (shipboard) applications. -
Page 7: Preparing The Environment
EMC performance is attained. Preparing the Environment Ensure that the environment in which you are using the NI-9263 meets the following specifications. Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C... -
Page 8: Load Connections
NI-9263: Use ferrules to terminate wires to the detachable connector. ■ Use the NI-9927 backshell kit with the NI-9263 with screw terminal or the ■ NI-9981 backshell kit with the NI-9263 with spring terminal. -
Page 9: Ni Services
NI product. Product registration facilitates technical support and ensures that you receive important information updates from NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX, 78759-3504, USA. © National Instruments © 2022 National Instruments Corporation.
