ITV1-TFU21
9 Zero-clear Function
• Press the 'Set' keys (Fig 6) together for 2 seconds or more.
• Press the 'Up' and 'Down' keys (Fig Display shows 'F03'.
6).
• Press the 'Set' keys (Fig Display shows 'OcL'(Flashing).
6).
• Press the 'Up' and 'Down' keys (Fig 6)
simultaneously. Display shows
'Ocl'.
• Press the 'Up' and 'Down' keys (Fig 6) simultaneously for 3 seconds or
more. Display shows 'clr' (1second).
• Zero-clear is complete.
10 Initialization
• Press the 'Set' key (Fig 6) simultaneously for 2 seconds or more.
• Press the 'Up' and 'Down' keys (Fig Display shows 'F99'.
6).
• Press the 'Set' keys (Fig 6). Display shows 'ini'(Flashing).
• Press the 'Up' and 'Down' keys (Fig 6)
simultaneously. Display shows
'ini'.
• Press the 'Up' and 'Down' keys (Fig 6) simultaneously for 5 seconds or
more. Display Turns OFF (1 second).
• Initialization is complete.
11 Installation & Maintenance
• If the electrical supply fails, settings are 'held' for a short period.
• If the air pressure fails with power 'on' the solenoid will 'flutter'. Turn off
the power.
• If the monitor output function is not used, ensure that the wire is totally
insulated.
• This product is pre-set at the factory and must not be dismantled by the
user. Contact your local SMC office for advice.
• Ensure, when installing this product, that it is kept clear of power lines to
avoid noise interference.
• Ensure that load surge protection is fitted when inductive loads are
present (i.e. solenoid, relay etc.).
• Ensure precautions are in place if the product is used in a 'free flow
output 'condition. Air will continue to flow continuously.
• Do not use a lubricator on the input side of this product. If lubrication is
necessary, place the lubricator on the 'output' side.
• Ensure all air is exhausted from the product before maintenance.
• Length of connector cable shall be 10 m maximum.
