CHIEF MTMPU Installation Instructions Manual

Fusion portrait medium tilt mount

Advertisement

Quick Links

I N S T A L L A T I O N I N S T R U C T I O N S
FUSION PORTRAIT MEDIUM TILT MOUNT
Spanish Product Description
German Product Description
Portuguese Product Description
Italian Product Description
Dutch Product Description
French Product Description
MTMPU

Advertisement

loading
Need help?

Need help?

Do you have a question about the MTMPU and is the answer not in the manual?

Questions and answers

Summary of Contents for CHIEF MTMPU

  • Page 1 I N S T A L L A T I O N I N S T R U C T I O N S FUSION PORTRAIT MEDIUM TILT MOUNT Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description MTMPU...
  • Page 2: Installation Instructions

    Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located between the MTMPU up to (and including) the display does not exceed 125 lbs (56.7 kg). WARNING: Use this mounting system only for its intended use as described in these instructions.
  • Page 3 Installation Instructions MTMPU DIMENSIONS NOTES: MINIMUM HORIZONTAL MOUNTING PATTERN 3.937" [100 mm] MAXIMUM HORIZONTAL MOUNTING PATTERN WITHOUT SWITCHING KNOB, 15.75" [400 mm] MAX HORIZONTAL MOUNTING PATTERN WITH SWITCHING KNOB, 18.10" [460 mm] +10.5 FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK ENGAGEMENT IS .58" [14.7 mm] OVERALL MOUNT DEPTH AT 0 OF TILT IS 2.40"...
  • Page 4: Tools Required For Installation

    MTMPU Installation Instructions TOOLS REQUIRED FOR INSTALLATION 3/16” (included) M5 (included) 7/32” (5.5mm) Wood Stud 3/8” (9.5mm) Concrete PARTS C (1) [Left Upright] B (1) A (1) [Right Upright] [Wall Mount] D (1) E (1) D1 (8) D2 (6) D3 (6)
  • Page 5 (See Figure 2) The MTMPU mounts are designed to be mounted to an 8" concrete, 8"x8"x16" concrete block or 2" x 4" wood studs (16" on center) wall. The MTMPU has brackets which allow the TV to be tilted. Locate Mounting Site...
  • Page 6 MTMPU Installation Instructions WARNING: EXPLOSION AND FIRE HAZARD! CUTTING OR DRILLING INTO GAS PLUMBING CAN CAUSE DEATH OR SERIOUS PERSONAL INJURY! ALWAYS make certain area behind mounting surface is free of gas, water, waste, or any other plumbing before cutting, drilling, or installing fasteners.
  • Page 7 The wall bracket may be adjusted side to side at the points of attachment (mounting slots). (See Figure 6) The location of the left and right upright brackets may be switched, with the knobs on the MTMPU upright brackets facing the inside of the mount. (See Figure 6)
  • Page 8 MTMPU Installation Instructions NOTE: Do NOT allow both upright brackets to be located on same side of wall bracket. (See Figure 9) NOTE: NEVER place both upright brackets to one side of the wall mount center line! (See Figure 9)
  • Page 9 (Screen not shown for clarity) Figure 11 Locking Mount (Optional) Add padlock (not included) to upright bracket tab to lock the MTMPU mount. (See Figure 12) Figure 10 Adjusting Tilt of Upright Brackets WARNING: IMPROPER TILT ADJUSTMENT MAY LEAD...
  • Page 10 MTMPU Installation Instructions...
  • Page 11 Installation Instructions MTMPU...
  • Page 12 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
