BLF 528-B3
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
Texte français page 18
WE'RE HERE TO HELP
NOUS POUVONS VOUS AIDER !
Want to watch a video that shows
how easy this DIY project will be?
Souhaitez-vous regarder une vidéo
démontrant la facilité de ce projet
de bricolage ?
Watch it now at:
SANUS.com/3183
Regardez-la maintenant sur :
SANUS.com/3183
Recommended placement
Get it right the first time!
HeightFinder
shows you where to drill.
Réussissez du premier coup !
HeightFinder
vous indique l'endroit
où percer.
Check it out at:
SANUS.com/2566
Découvrez-le sur :
SANUS.com/2566
Our US-based install experts are
standing by to help.
Nos experts en installation aux
États-Unis sont prêts à vous aider.
Call us at:
800-359-5520
Appelez-nous au :
800-359-5520
Or, chat at:
SANUS.com/chatSP
Ou, discutez en ligne sur :
SANUS.com/chatSP

Advertisement

loading
Need help?

Need help?

Do you have a question about the SANUS BLF528-B3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LEGRAND SANUS BLF528-B3

  • Page 1 BLF 528-B3 INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS Texte français page 18 WE’RE HERE TO HELP NOUS POUVONS VOUS AIDER ! Recommended placement Want to watch a video that shows Get it right the first time! Our US-based install experts are how easy this DIY project will be? HeightFinder shows you where to drill.
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service: +1 (800) 359-5520.
  • Page 3 Dimensions TV INTERFACE 7.9in 200mm 3.9in 100mm 15.7in 20.87in 400mm 530mm 23.6in 600mm 17.78in 451.6mm WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 36.2in 28 in 920mm 711mm 24.0in 610mm 15.7 in 13.8 in 46° 46° 11.5in 398mm 350mm 291mm 15°...
  • Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 5 STEP 1 Attach TV Bracket to TV 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or Irregular Back TV with extra space needed [for deep inset holes or cable interference] [TV brackets NOT resting flat on your TV]...
  • Page 6 Align with your TV's mounting hole pattern (VESA).
  • Page 7 NO SPACER SPACER NEEDED NOTE: Hanging tab is oriented to the TOP of your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV brackets to the TV.
  • Page 8 STEP 2A Attach Wall Plate Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
  • Page 9 STEP 2B Attach Wall Plate Solid Concrete or Concrete Block Installation CAUTION: Avoid potential personal injury or property damage! (Center) ● Mount wall plate directly onto concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ●...
  • Page 10 STEP 3 Hang TV onto Wall Plate 3.1 Attach Arm Assembly to Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! For CONCRETE APPLICATIONS: The arm assembly MUST remain centered in wall plate NOTE: For WOOD STUD APPLICATIONS, the arm assembly...
  • Page 11 CAUTION: Avoid potential personal injury or property damage! Locking screws must be tightened to secure the arm assembly 3.2 Attach TV to Arm Assembly HEAVY! You may need assistance with this step.
  • Page 12 CAUTION: Avoid potential personal injury or property damage! Locking screw must be installed to secure the TV to the arm assembly 1. Loosen the screw 2. Adjust handle enough to grab 3. Tighten the screw from the front of your TV.
  • Page 13 Manage Cables IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. 1. Slide to remove the cable covers 2. Route your cables through the arm assembly 3. Reattach the cable covers over the cables.
  • Page 14 TV Adjustments MOVING YOUR TV EXTEND / RETRACT TILT SWIVEL LEVEL ADJUSTMENT CAUTION: Screw MUST be loosened before turning screw CAUTION: Avoid potential personal injury or property damage! Always make sure your securement screw is tightened, so the TV is securely fastened to the arm assembly.
  • Page 15 TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the side tension knob by hand or use hex for additional tightening. NOTE: Once your TV is in place, tighten the tension knob to prevent unwanted movement.
  • Page 16 LATERAL SHIFT HEAVY! You may need assistance with this step. CAUTION: Avoid potential injuries or property damage! DO NOT adjust the arm position from center for CONCRETE APPLICATIONS. MUST remain centered in wall plate for all concrete applications! For WOOD STUD APPLICATIONS, 1.
  • Page 17 EXTEND / RETRACT -- ONLY IF NECESSARY Your TV should adjust easily when moved, then stay in place. ONLY if needed, adjust the extension/retraction arm tension with screw using hex key CAUTION: Avoid potential personal injury or property damage! DO NOT remove bolts , only turn enough for slight adjustment.
  • Page 18 CONSIGNES DE SÉCURITÉ IMPORTANTES Français – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ENTIÈREMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Veuillez lire au complet ces instructions pour vous assurer d’être à l’aise avec ce processus d’installation facile. Veuillez également consulter le manuel du propriétaire de votre téléviseur pour savoir si son installation présente des exigences particulières.
  • Page 19 1-3 Fixez le support de téléviseur PAGE 5 Desserrez les quatre vis Alignez-le avec le modèle de trou de montage de votre téléviseur (VESA). REMARQUE : la languette de suspension est orientée vers le HAUT de votre téléviseur. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! N’utilisez PAS d’ o utils électriques pour cette étape. Serrez les vis juste assez pour fixer la patte de fixation au téléviseur.
  • Page 20 Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein.
