Page 1 BMF 522-B3 INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS Texte français page 14 WE’RE HERE TO HELP NOUS POUVONS VOUS AIDER ! Recommended placement Want to watch a video that shows Get it right the ﬁrst time! Our US-based install experts are how easy this DIY project will be? HeightFinder shows you where to drill.
Page 2: Wall Construction
IMPORTANT SAFETY INSTRUCTIONS – PLEASE READ MANUAL PRIOR TO USE – SAVE THESE INSTRUCTIONS Please read through these instructions completely to be sure you’re comfortable with this easy install process. Check your TV owner’s manual to see if there are any special requirements for mounting your TV. If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer Service: +1 (800) 359-5520.
Page 3: Before You Begin
Dimensions TV INTERFACE TOP VIEW - EXTENDED 3.9in 7.9in 100mm 200mm 15.7in 400mm 15.7in 59deg 400mm SIDE VIEW - EXTENDED WALL PLATE 5deg 59deg 2.0in 52mm 12.3in 10.6in 312mm 270mm SIMULATED 55" FLAT SCREEN TV 5deg 22.3in 567mm FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED SIDE VIEW RETRACTED 17.3in...
Page 4 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
Page 5 STEP 1 Attach TV Bracket to TV 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length and Spacers Only one screw size fits your TV. NO SPACER SPACER NEEDED • Flat Back TV • Flat Back TV • Rounded or Irregular Back TV with extra space needed [for deep inset holes or cable interference] [TV brackets NOT resting flat on your TV]...
Page 6 Align with your TV's mounting hole pattern (VESA).
Page 7 NO SPACER SPACER NEEDED NOTE: Hanging tab is oriented to the TOP of your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV brackets to the TV.
Page 8: Wood Stud Installation
STEP 2A Attach Wall Plate Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1½ x 3½ in. (38 x 89 mm) ●...
Page 9 STEP 2B Attach Wall Plate Solid Concrete or Concrete Block Installation CAUTION: Avoid potential personal injury or property damage! ● Mount wall plate directly onto concrete surface (no wall covering) ● Minimum solid concrete thickness: 8 in. (203 mm) ● Minimum concrete block size: 8 x 8 x 16 in.
Page 10 STEP 3 Hang TV onto Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injury or property damage! Locking screw must be installed to secure the TV to the arm assembly...
Page 11: Manage Cables
Manage Cables IMPORTANT: Fully extend arm assembly to ensure enough slack in cables. 1. Slide to remove the cable covers 2. Route your cables through the arm assembly 3. Reattach the cable covers over the cables.
Page 12: Tilt Adjustment
TV Adjustments TILT ADJUSTMENT Your TV should adjust easily when moved, then stay in place. If your TV is too loose or too tight, adjust the side tension knob by hand or use hex for additional tightening. NOTE: Once your TV is in place, tighten the tension knob to prevent unwanted movement.
Page 13: Height Adjustment
HEIGHT ADJUSTMENT RAISE LOWER Hex Bit Extension may be useful (not included). REMOVING THE TV HEAVY! You may need assistance with this step.
Page 14: Avant De Commencer
CONSIGNES DE SÉCURITÉ IMPORTANTES Français – CONSERVEZ CES INSTRUCTIONS – VEUILLEZ LIRE ENTIÈREMENT LE MANUEL AVANT D’UTILISER CE PRODUIT Veuillez lire au complet ces instructions pour vous assurer d’être à l’aise avec ce processus d’installation facile. Veuillez également consulter le manuel du propriétaire de votre téléviseur pour savoir si son installation présente des exigences particulières.
Page 15: Gestion Des Câbles
1-3 Fixez le support de téléviseur PAGE 5 Desserrez les quatre vis Alignez-le avec le modèle de trou de montage de votre téléviseur (VESA). REMARQUE : la languette de suspension est orientée vers le HAUT de votre téléviseur. ATTENTION : Évitez les risques de blessures corporelles ou de dommages matériels ! N’utilisez PAS d’outils électriques pour cette étape. Serrez les vis juste assez pour fixer la patte de fixation au téléviseur.
Page 16 Legrand AV Inc. and its affiliated corporations and subsidiaries (collectively, “Legrand”), intend to make this manual accurate and complete. However, Legrand makes no claim that the information contained herein covers all details, conditions, or variations. Nor does it provide for every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change without notice or obligation of any kind. Legrand makes no representation of warranty, expressed or implied, regarding the information contained herein.
