2.3 About this machine
No. Name
1 Main unit
2 Original Cover OC-514
3 Reverse Automatic Doc-
ument Feeder DF-628
4 Fax Kit FK-513
5 Clean Unit CU-101
6 Mount Kit MK-747
7 Authentication Unit
AU-102
8 Authentication Unit
AU-201S
9 Working Table WT-506
10 Keypad KP-101
11 Keyboard Holder KH-102
12 Desk DK-513
13 Paper Feed Cabinet
PC-413
14 Paper Feed Cabinet
PC-213
15 Paper Feed Cabinet
PC-113
16 Finisher FS-534
17 Saddle Stitcher SD-511
18 Punch Kit PK-520
19 Relay Unit RU-514
20 Finisher FS-533
21 Mount Kit MK-602
22 Punch Kit PK-519
23 Job Separator JS-506
ineo 367/287/227
Description
Scans the original in the scanner section, and prints a scanned im-
age in the printer section.
Used to fix the loaded originals.
Automatically feeds and scans originals by page.
Required to use the fax function.
The Hard Disk is optional in some areas. When you use the fax
function, the optional Hard Disk must also be installed in this ma-
chine.
Collects small particles (UFP) generated in this machine to prevent
them from escaping this machine.
The Mount Kit MK-747 is required to install Clean Unit CU-101.
This unit is required to install Clean Unit CU-101.
Performs user authentication by scanning vein patterns in the fin-
ger.
To install the Authentication Unit AU-102, the Local Interface Kit
EK-608 or Local Interface Kit EK-609 is required in addition to the
Working Table WT-506.
Performs user authentication by scanning information recorded on
the IC card.
To install the Authentication Unit AU-201S, the Local Interface
Kit EK-608 or Local Interface Kit EK-609 is required in addition to
the Mount Kit MK-735.
This unit can also be installed on the Working Table WT-506.
Provides an area to temporarily place an original or other materials.
This is also used when the Authentication Unit AU-102 or Authen-
tication Unit AU-201S is installed.
It is equipped on the side of the Control Panel. Allows you to enter
numbers by using the Hardware Keypad.
Install this holder to use an external keyboard.
Used to place this machine on the floor.
Can load up to 2500 sheets of 8-1/2 e 11 (A4) size paper.
Can load up to 500 sheets respectively into the top and bottom
trays.
Can load up to 500 sheets into the top tray. (The bottom tray is a
storage box.)
Sorts, groups, or staples output sheets as required. To install the
Finisher FS-534, the Relay Unit RU-514 is required. Also, Desk
DK-513, Paper Feed Cabinet PC-413, Paper Feed Cabinet
PC-113, or Paper Feed Cabinet PC-213 must be installed on this
machine.
Used to add the center staple function to the Finisher FS-534.
Used to add the punch function to the Finisher FS-534.
Required to install the Finisher FS-534.
Sorts, groups, or staples output sheets as required. This unit can be
installed in this machine.
The Mount Kit MK-602 is required to install the Finisher FS-533.
Required to install the Finisher FS-533.
Used to add the punch function to the Finisher FS-533.
Used to separate output sheets into two trays in the body of the ma-
chine.
