Vicon Roughneck AI V2002D Quick Manual

Outdoor vandal dome cameras

Advertisement

Quick Links

Roughneck AI V2002D, V2005D and V2008 Dome Cameras
Quick Guide
Roughneck AI V2000D Series
Outdoor Vandal Dome
Cameras
Cybersecurity Notification: All network connected devices should use best
practices for accessing the device. To that end, these network cameras do
not have a default password. A user defined password with minimum
password strength requirements must be set to access the device. See page
18 of this Quick Guide for set-up instructions.
Be sure to check Vicon's website to be see if you have the most up-to-date
camera firmware.
Sales@collsam.com
(951)282-8707
HTTPS://COLLSAM.COM
Images May Not Reflect the Actual Product.
Design and specifications are subject to change without notice.
Support@collsam.com
(213)210-6744

Advertisement

loading
Need help?

Need help?

Do you have a question about the Roughneck AI V2002D and is the answer not in the manual?

Questions and answers

Summary of Contents for Vicon Roughneck AI V2002D

  • Page 1 A user defined password with minimum password strength requirements must be set to access the device. See page 18 of this Quick Guide for set-up instructions. Be sure to check Vicon’s website to be see if you have the most up-to-date camera firmware. Sales@collsam.com Support@collsam.com...
  • Page 2 Roughneck AI V2002D, V2005D and V2008 Dome Cameras Table of Contents Product Overview Physical Characteristics Installation, Mounting and Connections Package Contents Installation 2.2.1 Checking Appearance 2.2.2 Disassembling the Camera 2.2.3 Installing the Desiccant 2.2.4 Connecting the Cables 2.2.5 Mounting the Camera 2.2.6...
  • Page 3 Roughneck AI V2002D, V2005D and V2008 Dome Cameras WARNING  This camera operates at 12 VDC/24 VAC/PoE (IEEE 802.3af Class 3).  Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty.
  • Page 4 Roughneck AI V2002D, V2005D and V2008 Dome Cameras FCC Compliance Statement Information to the user: This unit has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 1 Product Overview 1.1 Physical Characteristics Figure 1 - 1: Physical Dimensions Unit: mm (in.) Figure 1 - 2: Parts Pictorial Index Sales@collsam.com Support@collsam.com HTTPS://COLLSAM.COM (951)282-8707 (213)210-6744 Images May Not Reflect the Actual Product.
  • Page 6 Roughneck AI V2002D, V2005D and V2008 Dome Cameras Name Description Bottom base of the camera dome. Camera Bottom Case The physical main body of the camera. Camera Module Screws of Camera Screws for fixing camera module to the camera bottom case.
  • Page 7 Roughneck AI V2002D, V2005D and V2008 Dome Cameras Typical Audio Input Wiring Figure 1 - 3: Internal Interface Pictorial Index Sales@collsam.com Support@collsam.com HTTPS://COLLSAM.COM (951)282-8707 (213)210-6744 Images May Not Reflect the Actual Product. Design and specifications are subject to change without notice.
  • Page 8 Name Description DI/DO (Digital Input/Output) ports are equipped for external devices, e.g., smoke detector, siren, microphone. • Alarm In: Via “AI” and “GND” ports; connect to external device that can trigger alarm input signals. • Alarm Out: Via “AO” and “COM” ports; connect to external DI/DO Port device to be triggered through alarm output signals.
  • Page 9 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2 Installation, Mounting and Connections Package Contents Check if all items listed below are included in the packing box.  Dome Camera * 1  Plastic Anchor * 4  Pan Head Screw (TP4) * 4 ...
  • Page 10 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.2 Disassembling the Camera Refer to the steps and figure below for correct disassembly order of the camera. Loosen the 3 screws of camera housing turning counterclockwise using the T20 security torx bit.
  • Page 11 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.3 Installing the Desiccant Lift to open the inner liner. Secure the desiccant (via the sticker that is attached to the desiccant) on the inside part of inner liner as shown in the following figure.
  • Page 12 Roughneck AI V2002D, V2005D and V2008 Dome Cameras Figure 2 - 3: Connecting Ethernet Cable Figure 2 - 4: Connecting BNC Cable Insert audio in/out cables and alarm in/out cables to the corresponding terminals of the camera, if required. NOTE: It is recommended to connect external microphones to ground (GND) on the digital I/O connector.
  • Page 13 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.5 Mounting the Camera  Use the mounting template to prepare a mounting area for surface mounting. 1. Place the supplied mounting template on a mounting surface. Drill 6 mm (0.2”) outer holes at the T1 (double gang box) or T2 (single gang box) template positions on the mounting surface.
  • Page 14 Roughneck AI V2002D, V2005D and V2008 Dome Cameras Plastic Anchor Pan Head Screw (TP4) Figure 2 - 7: Wall or Ceiling Surface Mount 4. Based on your installation requirements, use the bottom or side conduit hole on the camera bottom case for cable entry and feed the cables through the camera bottom case first.
  • Page 15 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.6 Positioning the Camera  Pan Adjustment (A) Rotate the lens camera assembly to the desired field of view. Note that the camera lens should not be rotated further than the point where the side conduit hole of the camera bottom case is located.
  • Page 16 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.6 Reassembling the Camera Assemble the camera housing with the camera bottom base, both of which have red dots for indicating alignment; then fasten the 3 screws of the lower dome with the T20 security torx bit to complete the installation.
  • Page 17 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 2.2.7 Lower Dome Defog A Defog function, which heats up the camera to overcome certain extreme weather conditions (e.g., snow or frost) that may harm the operation of camera, is embedded within this vandal dome camera. This defog heater ring is On between 140º...
  • Page 18 Roughneck AI V2002D, V2005D and V2008 Dome Cameras 3 Connection Network The camera, which is equipped with Ethernet RJ-45 network interface, can deliver live view image in real time via both Internet and Intranet. Review the topology drawings shown below.
  • Page 19 The camera can be accessed directly from its web page or using Vicon’s PRONTO Device Manager, which can be found on Vicon’s website. Note that when accessing the camera for the first time, a message will display to reset the password.
  • Page 20 Roughneck AI V2002D, V2005D and V2008 Dome Cameras PRONTO Device Manager PRONTO is Vicon’s device manager (Discovery tool) that can be used to discover all Vicon cameras on a system. The complete User Manual can be found on Vicon’s website.
