R&G RSET32 Fitting Instructions Manual

Adjustable rear set suzuki gsx-r1000 '17 and up

Advertisement

Available languages

Available languages

Quick Links

Page 1 of 21
FITTING INSTRUCTIONS FOR RSET32BK ADJUSTABLE REAR SET SUZUKI GSX-R1000 '17-
Please note that the way the kit is packed does not necessarily represent the way of mounting to the bike
Please note that in cases where kits are packed with rubber washers holding the components onto the bolt –
T
HE PARTS SHOWN MAY BE REPRESENTATIVE ONLY
Digital copies of these instructions are available to download from
This Kit Contains:
Item
= 1x
Left-Hand Side Assembly
1
Item 2 = 1x
Gear Shift Lever Assembly
Item 3 = 4x
M8x25mm Long Button Head Bolts
Item 4 = 1x
Right-Hand Side Assembly
Item 5 = 2x
M6x20mm Long Button Head Bolts
Item 6 = 1x
Brake Light Sensor Switch
Item 7 = 2x
Aluminium Sealing Washers
Item 8 = 1x
Brake Light Switch Bullet Connectors (CON0004)
Item 9 = 2x
Cable Ties
Tel: +44 (0)
420 89007 Fax: +44 (0)
1
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED BELOW.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT.
should be thrown away
GENERAL TORQUE SETTINGS
2x 10mm Open Ended Spanners
12mm Open Ended Spanner
Electrical/Crimping Pliers
Torque Wrench Up to 25Nm
Metric Allen Key Set up to 8mm A/F
Unit
, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
1
420 8730
1
!
(
FOR CLARITY OF INSTRUCTIONS ONLY
M4 BOLT = 8Nm
M5 BOLT =
2Nm
1
M6 BOLT =
5Nm
1
M8 BOLT = 20Nm
M
0 BOLT = 40Nm
1
TOOLS REQUIRED
Long Nose Pliers
R&G
www.rg-racing.com
1
the rubber washers
)
www.rg-racing.com
Email:
info@rg-racing.com
RSET32
