Summary of Contents for Biosan UVT-B-AR
- Page 2 Contents Safety Precautions General Information Getting Started Operation Specifications Maintenance Warranty and Claims Declaration of Conformity...
- Page 3 Safety Precautions The following symbols mean: Caution! Make sure you have fully read and understood the present Manual before using the equipment. Please pay special attention to sections marked by this symbol. Caution! Do not work in the cabinet or open the front protective screen while the open UV lamp is switched ON.
- Page 4 Do not operate the unit in premises where condensation can form. Operating conditions of the unit are defined in the Specifications section.
- Page 5 DURING OPERATION Do not operate the unit in environments with aggressive or explosive chemical mixtures. Please contact manufacturer for possible operation of the unit in specific atmospheres. Do not operate the unit without dust filters installed. Do not operate the unit if it is faulty or has been installed incorrectly. ...
- Page 6 UV recirculator consists of an airduct with a pressure fan, inlet and outlet dust filters and UV lamp installed inside. Operator working in a UV-cleaner box UVT-B-AR with a switched on UV recirculator is not exposed to UV emission, and the recirculator performs the cabinet working area UV processing, providing 100fold air change inside the cabinet per hour, without interrupting working process.
- Page 7 * —http://biosan.lv/efficiency_eng...
- Page 8 Advantages: No HEPA filters; UV-recirculator; Ozone free high density UV decontamination; Open UV lamp is switched off automatically in case of opening the protective front screen; Long life UV lamps (9000 h); Low noise level; ...
- Page 9 3.2. Complete set. Package contents: Standard set UVT-B-AR DNA/RNA UV-cleaner box..........1 pce spare dust filters................. 4 pcs spare fuse (inside the fuse holder) ............. 1 pce power cord ..................1 pce Operating manual, Certificate ............1 copy Optional accessories T-4 moving table for UV-cleaner box ...........
- Page 10 plug the power cable into the socket on the rear and position the unit so that there is easy access to the power switches and the power plug.
- Page 11 Operation 4.1. Connect the power plug to a grounded power socket. Switch ON the Power switch at the rear panel (position I). 4.1.1. Check the cable connections strength of the control block and the intermedi- ate mains cord. 4.2. UV exposition of the working place. Caution! Do not work in the cabinet or open the front protective screen while the open UV lamp is switched ON.
- Page 12 4.2.4. The open UV lamp can be switched off by pressing the Stop/Reset key (Fig.1/5). The set time of exposition will be saved in the memory. The set time won’t be saved after the complete switching off the unit. 4.2.5. If the set time of open UV light exposition is 0:00, pressing the Start key will make the unit operate continuously during 24 hrs or until the Stop/Reset key is pressed.
- Page 13 Specifications The unit is designed for operation in cold rooms, incubators and closed laboratory rooms at ambient temperature from +4°C to +40°C in a non-condensing atmosphere and maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C. Open UV lamp ..............TUV 25 W G13 UV-C Radiation type ..............
- Page 14 1000 W for 230V, or 600 W for 100 V, 120 V. Biosan is committed to a continuous programme of improvement and reserves the right to alter design and specifications of the equipment without additional notice.
- Page 15 Maintenance 6.1. If the unit requires maintenance, disconnect the unit from the electric circuit and contact Biosan or your local Biosan representative. 6.2. All maintenance and repair operations must be performed only by qualified and specially trained personnel. 6.3. Fuse replacement...
- Page 16 7.3. If any manufacturing defects are discovered by the Customer, an unsatisfac- tory equipment claim shall be compiled, certified and sent to the local dis- tributor address. Please visit www.biosan.lv, Technical support section to ob- tain the claim form. 7.4.
- Page 17 Declaration of Conformity...
- Page 18 Biosan SIA...
- Page 19 Ratsupites 7, build. 2, Riga, LV-1067, Latvia Phone: +371 6742 6137, Fax: +371 6742 8101...
- Page 20 http://www.biosan.lv...
- Page 21 Version 3.03 — July 2014...
