Summary of Contents for Biosan UVC-AR
- Page 2 If you have any feedback on our products or services, we would like to hear from you. Please send all feedback to: Manufacturer: SIA Biosan Ratsupites iela 7 k-2, Riga, LV-1067, Latvia Phone: +371 674 261 37 Fax: +371 674 281 01 www.biosan.lv...
-
Page 3: Table Of Contents
Contents About this edition of user instructions ............... 3 Safety precautions ....................3 General information ....................5 Getting started ......................6 Operation ......................... 7 Specifications ......................9 Ordering information ....................11 Care and maintenance ................... 12 Storage and transportation ..................14 Warranty ......................... - Page 4 General safety • The protection provided by the equipment may be impaired if the equipment is used with accessories (shelves, furniture) not provided or recommended by the manufac- turer, or used in a manner not specified by the manufacturer. • Save the unit from shocks and falling.
-
Page 5: General Information
Box for clean operations with DNA/RNA samples with built-in recirculator is a pa- tented solution (patent LV13115 from 20/05/2004, Dr. biol. V. Bankovsky). Microbiological studies at the R&D Department of Biosan led by Dr. biol. V. Bankov- sky demonstrated a high level of biosafety and efficacy of UV-cleaner box (maximal level of... -
Page 6: Getting Started
Figure 1. Recirculator scheme. 1. UV lamp. 2. Fan and input filter. 3. UV indicator. 4. Output filter Getting started Unpacking. Remove packing materials carefully and retain them for future shipment or storage of the unit. Examine the unit carefully for any damage incurred during transit. -
Page 7: Operation
T-4L LF-1 Setup. If the moving table is used, unpack it carefully and assemble according to the en- closed assembling scheme. Place the unit upon stable surface. Ensure that the unit is placed on a solid, level surface not less than 720x550 mm (1290x600 mm for UVT-S-AR model), which is able to support its weight and the weight of equipment and materials inside, for in- stance on the T-4 / T-4L table. - Page 8 Note. Open UV lamp operation can be checked with the visible light lamp switched off (switch 1 is OFF). Use the indicator in the centre of recircu- lator cover (fig. 1/3) to check operation of UV lamp inside the recirculator. If indicator lights from inside while switch 2 is ON, then the UV lamp is functioning.
-
Page 9: Specifications
80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C. Biosan is committed to a continuous programme of improvement and reserves the right to alter design and specifications of the equipment without additional notice. - Page 10 UVC/T-AR UVC/T-M-AR UVT-B-AR UVT-S-AR Model Compact Compact Compact Double Noise level < 45 dB < 47 dB Working surface 490x645 mm 500x1210 mm Opening height 165 mm 190 mm (max 210 mm) 190 mm (max 220 mm) Opening levels Full height 1/3, 2/3 and full height Cable inlet and 3 sock- Power inside the box (see 7.1)
-
Page 11: Ordering Information
Caution! Overall consumed power of devices connected through internal mains sockets should not exceed 1000 W for 230V~, or 600 W for 100–120 V~. To inquire about or order the optional accessories, contact Biosan or your local Bio- san representative. -
Page 12: Care And Maintenance
Service. 8.1.1 If the unit is disabled (e.g., lamps not working, no reaction on key and switch presses) or requires maintenance, disconnect the unit from the mains and contact Biosan or your local Biosan representative. 8.1.2 All maintenance and repair operations (except listed below) must be performed only by qualified and specially trained personnel. - Page 13 For decontamination, we recommend using a special DNA/RNA removing solution (e.g. Biosan PDS-250). After washing the inside parts of the box it is necessary to rub them dry. Caution! Never use organic solvent based compounds, pure alcohol, alcohol-con- taining cleaners (more than 20%) or ammonia containing cleaners for acrylic glass.
-
Page 14: Storage And Transportation
• For UVC/T-AR & UVT-B-AR, the Basic Plus class model, extended warranty is a paid service. Contact your local Biosan representative or our service department through the Technical support section on our website at the link below. 10.6 Description of the classes of our products is available in the Product class descrip- tion section on our website at the link below. -
Page 15: Eu Declaration Of Conformity
14 digits styled XXXXXXYYMMZZZZ, where XXXXXX is model code, YY and MM – year and month of production, ZZZZ – unit number. Manufacturer SIA BIOSAN Latvia, LV-1067, Riga, Ratsupites 7 k-2 The objects of the declaration described above is in conformity with the following... - Page 16 Biosan SIA Ratsupites 7 k-2, Riga, LV-1067, Latvia Phone: +371 67426137 Fax: +371 67428101 http://www.biosan.lv Edition 3.-6.02 – March of 2021...
