Periodical maintenance
UVR-M does not require periodical technical maintenance, except cleaning.
Cleaning. Standard ethanol (75%) or any other cleaning liquids can be used for cleaning
and disinfecting of the device, if it does not contain any strong organic solvents (such
as acetone, toluene or benzene).
In order to ensure proper efficiency in the long term run it is recommended to clean the
UV-recirculator and dust filters once a month. To do so unscrew the twelve screws on
the rear panel, take off the panel and blow off dust from the lamps and reflectors
preferably by compressed air to ensure integrity of reflective coating.
The following spare parts are available for UVR-M:
Starting
No.
version/date
1
V.1AA / 21.20.2009
2
V.1AA / 21.20.2009
3
V.1AA / 21.20.2009
4
V.1AA / 21.20.2009
5
V.4AA / 21.09.2021
6
V.1AA / 21.20.2009
7
V.1AA / 21.20.2009
8
V.4AA / 21.09.2021
UVR-M Service Manual - V.4AA
Service Manual for
Recirculator UVR-M
Compatibility
V.4AA
Fan Filter medium FE80F 145
V.4AA
Fuse
V.4AA
UV lamp
V.4AA
Starter
-
Fan
V.4AA
Switch
V.4AA
Ballast
-
Casing
Version 5 - October 2021
Spare part
Marking
FSMO 1A
TUV 25W Philips
S10 Philips
XFA28025HBT
WIP12BRT
LN30.801
UVR-M
Article
BS-000000-S29
BS-000000-S21
BS-000000-S09
BS-000000-S26
BS-040105-S12
BS-000000-S04
BS-000000-S25
BS-040110-S08
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Biosan UVR-M
Summary of Contents for Biosan UVR-M
- Page 1 Recirculator UVR-M Periodical maintenance UVR-M does not require periodical technical maintenance, except cleaning. Cleaning. Standard ethanol (75%) or any other cleaning liquids can be used for cleaning and disinfecting of the device, if it does not contain any strong organic solvents (such as acetone, toluene or benzene).
- Page 2 – pull out fan from rubber sleeve (fig.2/7); – unscrew the screw (fig.2/3) and release the ground wire from the Fan; – replace the Fan; – re-assemble the unit. Lamp cover removed fig.2 UVR-M Service Manual - V.4AA Version 5 - October 2021 Page 2...
- Page 3 – unscrew the nut (fig.2/9) and remove the fuse holder; – unscrew the screw (fig.2/10) and remove the power cord holder; – replace the casing; – re-assemble the unit. fig.4 UVR-M Service Manual - V.4AA Version 5 - October 2021 Page 3...
- Page 4 Connect the live and neutral pins of the power supply plug together. Use a 500V insulation resistance tester and measure the insulation resistance between the earth and live/neutral pins. This should be greater than 2 Mohm. UVR-M Service Manual - V.4AA Version 5 - October 2021 Page 4...
- Page 5 UVR-M Service Manual - V.4AA Version 5 - October 2021 Page 5...
