1. General
This device is attached to the DDL-8000CS. By installing the multi-layered section detection sensor, sewing
parameters can be automatically switched at multi-layered sections while sewing.
Switchable sewing parameters
Detectable material thickness Detectable material thickness
Detection resolution
* Multi-layered section of material that is less than 2 mm in thickness is likely to be affected by the feed dog
height. Stable detection, therefore, cannot be carried out.
In addition, it is not possible to detect two or more multi-layered sections with different heights.
2. Multi-layered section detection sensor kit parts list
Multi-layered section detection sensor kit parts number : 40299026
❺ ❺
❻ ❻
No. Parts No.
❶ ❶
40299025
❷
40299027
❸
40297939
❹
40297951
❺
40299028
❻
40298669
Stitch length and sewing speed
Max. 13 mm
0.1 mm
❸ ❸
❹ ❹
Description
Multi-layered section detection
sensor (connection unit)
Magnet fixing base (asm.)
Stopper
Setscrew
Setscrew
Connector 8R
– 1 –
❷ ❷
Qty
1
1
1
3
1
1
❶ ❶
