- Page 1 INDUSTRIAL SEWING MACHINE Attachment MODEL MP-G10-TH TECHNICAL MANUAL Upper Thread-Holding Device A181E018P01...
-
Page 3: For Safe Use
FOR SAFE USE Before the installation, operation, and inspection for this product, read the “FOR SAFE USE” and the technical manuals carefully. Also read the other technical manuals, “Sewing Machine Head”, “Control Unit” and “Operation Panel” describing some instructions, which are not in this manual, and use the sewing machine properly. -
Page 4: Applicable Models
1. Features Upper Thread-Holding Device will improve the quality of the sewing start point. By gripping the upper thread after thread trimming sewing end, to prevent the thread fall out at the sewing start point. 2. Applicable models PLK-G1010 Fig.1 Mounting example of the upper thread holding mechanism 3. - Page 5 4. Configuration The Fig. numbers in the drawing correspond to the part numbers given in the following explanations. When ordering service parts, please specify in the Parts No. (M********). 4.1 Upper thread holding mechanism An example of a mounting bracket 107A 107B (Not included)
- Page 6 4.2 Pneumatic pressure control unit (Parts list) 部品コード 数量 品 名 Description Parts No. Amt. Req. MH25A1601 ﾃﾞﾝｼﾞﾍﾞﾝﾄﾘﾂｹｲﾀ Valve mounting plate M91066004 SW-PW ﾌﾟﾗﾏｲﾅﾍﾞﾈｼﾞ M4X25 Screw M4X25 ME10X0599 ﾃﾞﾝｼﾞﾍﾞﾝｸﾐﾀﾃ Solenoid valve assy M90511050 ｻﾞｶﾞﾈ 5 Washer 5 M95003017 ｾﾌﾃｨｿｹｯﾄ M5X8 Safety socket bolt M5X8 MH10A8508 ｾﾂｿﾞｸﾃﾞﾝｾﾝｸﾐﾀﾃ...
-
Page 7: Assembly Procedures
5. Assembly procedures CAUTION ★ To work in the presence of residual pressure in the pneumatic circuit It is dangerous. Please work after you remove the residual pressure always. The method of removing the residual pressure, and pull up the handle of the pressure regulating filter regulator, can be done by turning counter-clockwise until the pressure gauge shows 0. - Page 8 5.3 How to setup and cable connection (1) Remove the circuit board cover on the back of the sewing machine. (2) Disconnect the cable connector of the wiper connected to CON11 on the circuit board. (3) Connect the connector of Fig.No.203 cable assy to CON11 on the circuit board. (4) Connect the connector of sensor of the air cylinder to CON9 on the circuit board.
-
Page 9: Operation
Default value After changing the setting Input signal Signal name Thread trimming protection signal Logical setting normal reversed 6. Operation CAUTION Assembly of this device is completed, please check your work once again. Because there is a case to unexpected behavior, please away from the sewing machine when the power is turned on and the air pressure. - Page 10 MEMO...
- Page 12 Printed in Japan...
