- Page 1 POLON 4000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM EWS-4001 MICROPROCESSOR ADDRESSABLE MULTI-OUTPUT CONTROL DEVICE Installation and Maintenance Manual IK-E304-001GB II Edition...
- Page 2 Any nonconformity with the instructions contained in the manual may be harmful or may cause violation of the law in force. POLON-ALFA bears no responsibility for any damage resulting from usage inconsistent with the manual. A waste product, unsuitable for further use, shall be passed to a waste electric and electronic equipment collection point.
- Page 3 The device EWS-4001 addressable multi -output control device is designed to control different fire- fighting automatic equipment, in particular for switching-on pre-fire warning sound systems and synoptic signs. The EWS-4001 device can operate only in lines/loops of POLON 4000 addressable fire alarm systems.
- Page 4 PRINCIPLE OF PERATION The communication between the control panel POLON 4000 and the multi-output device EWS- 4001 is by using two wires addressable detector line. On the order from the control panel ensues the change of the position of relays contacts and activation of fire protection units or choose of channel of voice alarm system.
- Page 5 IK-E286-001GB be used. During the installation the attention must be paid to the proper arrangement of spline and hole which are placed on the opposite side. Installation wires should be insert thought seal glands PG7 and connect to the set of connectors according to the description.
- Page 6 IK-E304-001GB Fig.1 Construction and dimensions of EWS-4001...
- Page 7 IK-E286-001GB House of EWS-4001 Detector line Detector line ROP-4001 TUN-4046 circuit (loop) Ekran printed Controlled circuit of unit EWS-4001 COM8 Controlled unit COM7 Controlled unit COM2 Controlled unit COM1 Fig.2 Example of connection of EWS-4001 in addressable detector line...
- Page 8 IK-E304-001GB Fig. 3 Connectors of EWS-4001 IK-E304-001GB/01.2013...
