Polon-Alfa POLON 4000 Installation And Maintenance Manual

Interactive fire alarm system wireless manual fire call points
Hide thumbs Also See for POLON 4000:

Advertisement

Table of Contents

IK-E352-001
1
INTERACTIVE FIRE ALARM SYSTEM
POLON 4000 and POLON 6000
WIRELESS MANUAL FIRE CALL POINTS
ROP-4007 and ROP-4007H
Installation and Maintenance Manual
IK-E352-001
IC edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POLON 4000 and is the answer not in the manual?

Questions and answers

Related Manuals for Polon-Alfa POLON 4000

Summary of Contents for Polon-Alfa POLON 4000

  • Page 1 IK-E352-001 INTERACTIVE FIRE ALARM SYSTEM POLON 4000 and POLON 6000 WIRELESS MANUAL FIRE CALL POINTS ROP-4007 and ROP-4007H Installation and Maintenance Manual IK-E352-001 IC edition...
  • Page 2 Failure to observe the instructions in this manual may be dangerous or result in a breach of regulations in force. POLON-ALFA is not liable for damages resulting from the use inconsistent with this manual. A waste product, unsuitable for further use, shall be passed to a waste electric and electronic equipment collection point.
  • Page 3 IK-E352-001 POLON-ALFA S.A. 85-861 Bydgoszcz, ul. Glinki 155 Manual Call Point ROP-4007, ROP-4007H Intended use: Fire safety – call points intended for transmitting information about a fire to fire alarm control panels upon manual activation. ROP-4007 – for indoors operation ROP- 4007H –...
  • Page 4 IK-E352-001 H a r m o n i z e d t e c h n i c a l s p e c i f i c a t i o n Pe rf or man c Prod u ct es s en t ial f ea tu r es E N 54 - 11 : 20 01 p rop ert i es A1 :2 00 5...
  • Page 5 IK-E352-001 H a r m o n i z e d t e c h n i c a l s p e c i f i c a t i o n Prod u ct es s en t ial f ea tu r es Fe atu r es E N 54 - 11 : 20 01 A1 :2 00 5...
  • Page 6 IK-E352-001 H a r m o n i z e d t e c h n i c a l s p e c i f i c a t i o n E s s en t ial ch a ra ct eris ti cs of th e p r od u c t Fe atu r es E N 54 - 25 : 20 08 +A C 20 1 0...
  • Page 7 IK-E352-001 H a r m o n i z e d t e c h n i c a l s p e c i f i c a t i o n E s s en t ial ch a ra ct eris ti cs of th e p r od u c t Fe atu r es E N 54 - 25 : 20 08 +A C 20 10...

  • Page 8: Intended Use

    The ROP-4007 and ROP-4007H Wireless Manual Fire Call Points communicate with POLON 4000 and POLON 6000 Fire Alarm Control Panels via the ACR-4001 Radio Adapter. The manual call points are battery-powered.

  • Page 9: Safety Conditions

    The maintenance works and periodical inspections should be conducted by authorized employees of companies which have been authorized or trained by POLON-ALFA personnel. All repairs must be carried out by the manufacturer. POLON-ALFA is not responsible for the operation of equipment maintained and repaired by unauthorized personnel. 3.2 Eye protection against dust For works creating lots of dust, especially when drilling holes, wear protective goggles and dust mask.

  • Page 10: Operation Description

    IK-E352-001 5 OPERATION DESCRIPTION Activation of the manual call point: entering the alarm state occurs upon hitting the glass (tilting it) and then by pressing the button. The background color of the manual call point arrows changes from black to yellow. The information about pressing the button is sent to the fire alarm control panel, which transmits the signal to the manual call point activating the LED diode signaling the manual call point activation with red flashes.

  • Page 11: Installation

    IK-E352-001 Fig. 3 Clearing the alarm state Note: If the glass will be pulled instead of being hit (not in accordance with the instructions on the manual call point) and the button is not pressed (the manual call point will not be put into an alarm condition), press the glass to the operating zone and insert the key from the bottom of the device until it stops, in order to lock the glass in position.
  • Page 12 IK-E352-001 Fig. 4 Dimensions and mounting holes of the manual call point Fig. 5 Dimensions and mounting holes of the RM-60-R Masking Frame 6.2 Battery installation To access the plate with batteries, two keys (with flat tips) should be pressed inwards from the sides of the device.
  • Page 13 IK-E352-001 Fig. 6 How to open the manual call point Fig. 7 Manual call point after opening...

  • Page 14: Operation And Maintenance

    IK-E352-001 6.4 Glass replacement If it is necessary to replace the glass, tilt the body of the manual call point (see Fig. 6), pull out the glass, remove the spring. Install the spring on the hinge of the new glass according to Fig. 8. Fig.
  • Page 15 ROP-4007 Manual Call Point is power-supplied by two ER14505V lithium batteries rated at 3.6V. The manufacturer recommends batteries produced by EVE. These batteries are supplied by POLON-ALFA together with the call points and sold separately to replace used batteries in call points working on premises.
  • Page 16 III. Choosing a location, if the installation location of the adapter is known and the position of the manual call points may be changed. The procedure applies only to the POLON 4000 system. When testing communication between the adapter and the manual call point, try to test the devices at the installation heights as close to the real ones as possible.

  • Page 17: Packing, Transportation, Storage

    IK-E352-001 5. Verify if there is a good connection with the adapter in the planned component installation location. This is presented with 3 regular LED flashes in red and no flashes in yellow. Additionally, in the control panel, in the SYSTEM TESTING COMPONENTS (TESTOWANIE ELEMENTÓW SYSTEMU) ->...
