IK-E362-001
1
ADDRESSABLE ACOUSTIC AND VISUAL
ALARM DEVICES (SOUNDER BEACON)
SAB-6001 and SAB-6006
_________________________________________________________________________________
INSTALLATION AND MAINTENANCE
SS
MANUAL
IK-E362-001
Rev. 1
SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Polon-Alfa SAB-6001
Summary of Contents for Polon-Alfa SAB-6001
- Page 1 IK-E362-001 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES (SOUNDER BEACON) SAB-6001 and SAB-6006 _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E362-001 Rev. 1 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 2 IK-E362-001 The SAB-6001 and SAB-6006 addressable acoustic alarm devices, which are the subject of this Manual, meet the essential requirements of the following European Parliament and Council (EU) regulations and EU directives: CPR/305/2011 Regulation (EU) of the European Parliament and of the Council of 9 March 2011 laying down uniform conditions for the marketing of construction products and repealing Council Directive 89/106/EEC;...
-
Page 3: Table Of Contents
Repairs and maintenance ...................... 15 8.2. Work at height ........................15 8.3. Eye protection against dust ....................15 Storage and transport ......................16 9.1. Storage ..........................16 9.2. Transport ..........................16 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES... -
Page 4: Intended Use
(only for the POLON 6000 system). The level of emitted sound and light does not change depending on the value of the supply voltage. SAB-6001 and SAB-6006 are programmable items. With a USB cable (A → MiniUSB) and dedicated software, it is possible to configure acoustic sequences specific to the requirements of a particular facility and compliant with the PN-EN 54-3:2003 + A2:2007 standard. - Page 5 IK-E362-001 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
-
Page 6: Technical Specification
Tightness of the housing IP 21C Dimensions incl. the socket Ø 115 mm x 94 mm Weight incl. the socket 0.26 kg programmable from the control Method of address coding panel SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES... - Page 7 IK-E362-001 Key: Promień pokrycia [m] – Coverage radius [m] Wysokość [m] -Height [m] Height of Coverage radius [m] installation 6.95 8.25 7.25 7.35 7.45 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 8 IK-E362-001 9.05 7.45 8.95 7.35 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
-
Page 9: Description Of Construction
The SAB-6000 (also in 6001 and 6006 versions) are installed in the G-40S base wired to the detection line and can be connected to external power supply. Figure 3/1 Mechanical construction of the SAB-6000 alarm device SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES... -
Page 10: Description Of Operation
The control panels of POLON 6000 and POLON 4000 systems communicate with SAB-6001 and SAB- 6006 alarm devices by means of a two-wire addressable detection line. The unique, fully digital communication protocol allows any information to be transmitted from the control panel to the alarm device and from the alarm device to the control panel. -
Page 11: Operation Mode
Czas trwania sekwencji – Duration of sequence In the SAB-6001 or the SAB-6006 alarm device, in case voice message is not configured, the sequence consists of a warning signal only, as the silent breaks are therefore not used. Available alarm horns were described in Appendix B. - Page 12 Guidelines for determining the power consumption in a specific case are presented in Appendix A. The SAB-6001 alarm device does not offer the possibility of programming voice warning sequences. The sequence always has of a warning signal only.
-
Page 13: Description Of Operation
The functionality of the device can be checked by consecutive activation of acoustic alarms from the control panel. Damaged alarm devices shall be delivered to the producer (POLON-ALFA S.A., ul. Glinki 155 , 85-861 Bydgoszcz) for repair. -
Page 14: Installation Of Alarm Devices
IK-E362-001 7. Installation of alarm devices The SAB-6001 and SAB 6006 alarm devices shall be installed (height, positioning) in accordance with the specified design guidelines. They are installed in facilities where any appearance of fire should be signalled. The alarm devices operate in closed loop lines, closed loop lines with straight branching or in radial detection lines of the POLON 6000 and POLON 4000 systems (see Operation and Maintenance Manual for the POLON 6000 and POLON 4000 control panels). -
Page 15: Safety Conditions
Maintenance works and periodical inspections must be carried out by authorised personnel of companies authorised or trained by POLON-ALFA. All repairs must be carried out by the producer. POLON-ALFA shall not be held liable for the operation of equipment maintained and repaired by unauthorised personnel. 8.2. Work at heights Work at heights for installation of alarm devices must be carried out with utmost caution using operational equipment and tools. -
Page 16: Storage And Transport
The temperature during transport should not be lower than - 40°C and not higher than + 70°C, and the relative humidity shall not exceed 95% at + 45°C or 80% at + 70°C. SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES... - Page 17 ÷ 16.0 V). If the SAB-6006 alarm device emits a warning signal with voice message, the maximum power con- sumption should be considered to be the value for horn No. 11. SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 18 SS 03 17 11 A "triangular" tone, the frequency cyclically rises and falls, modified “PIES MODULATION” Intermittent tone of 2600 Hz frequency A 'saw tooth' ascending tone, A 'saw tooth' ascending tone, SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 19 101 dB 100 dB 87 dB 94 dB 85 dB 89 dB 91 dB 91 dB 86 dB 85 dB 95 dB 94 dB 100 dB 100 dB 87 dB 93 dB SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 20 15° 45° 75° 105° 135° 165° 94 dB 96 dB 103 dB 103 dB 90 dB 91 dB 83 dB 90 dB 93 dB 93 dB 86 dB 84 dB Notes: SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 21 IK-E362-001 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
- Page 22 IK-E362-001 SAB-6001 and SAB-6006 ADDRESSABLE ACOUSTIC AND VISUAL ALARM DEVICES...
