- Page 1 IK-E333-001-GB, Edition III, 07.2024 ALARMING DEVICES SG-1, SG-2 _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E333-001-GB Edition III _________________________________________________________________________________ SG-1, SG-2 Alarm devices...
- Page 2 IK-E333-001-GB, Edition III, 07.2024 The SG-1 and SG-2 alarm devices, that are the subject of this IK meet the essential requirements of the directive: The electromagnetic compatibility (EMC) Directive 2021/30/EU Read the manual carefully before assembling and commissioning. Any nonconformity with the instructions contained in the manual may be harmful or may cause...
-
Page 3: Table Of Contents
Repair and Maintenance ........................... 10 6.2. Work at height ..............................10 6.3. Eye protection against dust ..........................10 6.4. Protection against electric shock ........................11 Storage and Transport ......................11 7.1. Storage................................11 7.2. Transport ................................11 _________________________________________________________________________________ SG-1, SG-2 Alarm devices... -
Page 4: Design
IK-E333-001-GB, Edition III, 07.2024 Design The SG-1 and SG-2 alarming devices are designed for optical and acoustic signalling of alarm states in cooperation with fire extinguishing or gas detection systems. The signalling device is available in single- and double-sided versions - the illuminated inscription is placed on one or both sides of the device. -
Page 5: Technical Data
When opening the frame of the alarm device attention must be paid to an unattached plate as it is held in the guides located on both parts of the housing. Figure . 4.1 Opening procedure. _________________________________________________________________________________ SG-1, SG-2 Alarm devices... - Page 6 If the siren is mounted to the wall keys must be insert as far as the stop as shown in Fig. 4.2 and only the right key must be pulled in order to open the device. Figure. 4.2 Wall mounted device opening procedure ___________________________________________________________________________________ SG-1, SG-2 Alarm devices...
- Page 7 _________________________________________________________________________________ SG-1, SG-2 Alarm devices...
- Page 8 Operation and Maintenance Documentation. An example connection of the SG-1 signaling device to the CDG 6000 gas detection center is shown in Fig. 4.4; the PK1 relay output is used. In the control panel configuration, set the selected source (e.g.
-
Page 9: Device Characteristics
IK-E333-001-GB, Edition III, 07.2024 The SG-1, SG-2 signalling devices are additionally equipped with a jumper that allows to configure the signalling mode (continuous or pulse) without changing device's power supply control characteristics. Figure. 4.6 Lighting mode configuration The jumper in position 1 configures the continuous signalling mode (factory setting). -
Page 10: Safety Conditions
6.2. Work at height Work at height related to the installation of SG-1, SG-1 alarm devices must be carried out with special care using equipment and tools in sound condition. Please pay particular attention to the stability of ladders, elevators, hoists, jacks etc. -
Page 11: Protection Against Electric Shock
Storage and Transport 7.1. Storage SG-1, SG-2 devices should be stored in closed rooms, with no corrosive fumes or gases, at the temperature range from 0 °C to +40 °C, with relative humidity not exceeding 80 % at the temperature of +35 °C. - Page 12 IK-E333-001-GB, Edition III, 07.2024 ___________________________________________________________________________________ SG-1, SG-2 Alarm devices...
