- Page 1 IK-E400-001-GB, Edition 2, 09.2023 MANUAL CALL POINTS ROP-3000 and ROP-3000H POLON 3000 FIRE ALARM SYSTEM _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E400-001-GB Zmiana 2...
- Page 2 IK-E400-001-GB, Edition 2, 09.2023 Manual call points ROP-3000 and ROP-3000H which is the subject of this instruction, meet the essential requirements of the following regulations of the European Parliament and of the Council (EU) and European Union directives: CPR CPR/305/2011 Regulation (EU) of the European Parliament and of the Council of 9 March 2011 laying down harmonised conditions for the marketing of construction products repealing Council Directive 89/106/EEC;...
-
Page 3: Table Of Contents
IK-E400-001-GB, Edition 2, 09.2023 Content 1 PURPOSE ........................... 4 2 TECHNICAL SPECIFICATION......................4 3 SAFETY CONDITIONS ........................4 3.1 Repairs and maintenance ....................... 4 3.2 Anti-dusting eye protection ......................4 4 DESIGN DESCRIPTION ........................ 5 5 PRINCIPLE OF OPERATION ......................5 6 INSTALLATION ........................... -
Page 4: Purpose
IK-E400-001-GB, Edition 2, 09.2023 1 PURPOSE The ROP-3000 and ROP-3000H manual call points are designated for operation in addressable loops of the POLON 3000 control panel. They are addressable devices installed in order to transfer information about a noticed fire by their manual actuation. Both version of manual call points are equipped with internal short-circuit isolators. -
Page 5: Design Description
IK-E400-001-GB, Edition 2, 09.2023 4 DESIGN DESCRIPTION The manual call point consists of a body and a base connected with a hinge. The manual call point body contains its main parts: a printed circuit board with an electronic circuit, micro-switch and connector to install detecting line wires. A two-colour illuminating diode, indicating the alarm or fault mode, is located in the device upper part behind the glass. - Page 6 Fig. 5.2 and insert the key (T end) from the bottom until the arrows in the operation area change their colour from yellow to black. After the key removal, the cover is blocked again in its normal position. Glass Rys. 5.2 Alarm mode reset MANUAL CALL POINTS ROP-3000 and ROP-3000H...
-
Page 7: Installation
IK-E400-001-GB, Edition 2, 09.2023 Note: If the cover is not hit but pulled aside (inconsistently with the instruction placed on the call point) and the push button is not pressed (the call point alarm mode is not activated), it is necessary to press the cover down towards the operation area and block it in this position inserting the key from the bottom of the call point. -
Page 8: Wire Arrangement
For the manual call point easy connection some wire reserve shall be left of the length as follows (by installation going from top of MCP): - ca. 40 cm in case of surface mounting installation, - ca. 30 cm in case of semi-flush installation. MANUAL CALL POINTS ROP-3000 and ROP-3000H... -
Page 9: Wire Connection
IK-E400-001-GB, Edition 2, 09.2023 6.3 Wire connection Loop-shaped detecting line wires are connected to “+” and “-“ contacts, separately for an input and an output. In case of screened wires, the screens are joined together and connected to the contact on the board marked as “E”. -
Page 10: Plastic Cover Replacement
Figure 6.4.1. Rys. 6.4.1 Cover spring assembly Then it is needed to insert the cover into the casing rails and hook the spring on a ledge in the call point casing acc. To Figure 6.4.2. MANUAL CALL POINTS ROP-3000 and ROP-3000H... - Page 11 IK-E400-001-GB, Edition 2, 09.2023 Rys. 6.4.2 Spring fastening to casing A set of 3 spare plastic covers is described as SZ-60.
-
Page 12: Maintenance And Servicing
+5 °C to +40 °C and relative humidity between 40 % and 80 %, away from heating devices. The storage period should not exceed 24 months. MANUAL CALL POINTS ROP-3000 and ROP-3000H... - Page 13 IK-E400-001-GB, Edition 2, 09.2023...
