POLON 4000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM TUN‐4043 ADDRESSABLE MULTI‐STATE UNIVERSAL HEAT DETECTOR Installation and Maintenance Manual IK‐E283‐002GB IIIA Edition ...
Page 2
2 IK‐E283‐002GB The TUN‐4043 heat detector covered by the present manual complies with the requirements of the following European Union directives: CPD 89/106/EWG on construction materials; EMC 2004/108/WE on electromagnetic compatibility. The TUN‐4043 Heat Detector has been approved with the EC‐Certificate of Conformity No. 1438/CPD/0018 issued by the Scientific and Research Centre for Fire Protection (CNBOP) Józefów, Poland, an EU notified authority No. 1438, confirming its compliance with the requirements of PN‐EN 54‐5:2003 standard. ...
Page 3
1 PURPOSE s designed for The TUN‐4043 programmable addressable microprocessor based heat detector i detection of fire hazard or fire appearance signalling in closed premises, where during the first phase of a fire an occurrence of temperature rise may be observed, or where ambient temperature may exceed the set fire danger level. It enables programming of appropriate actions in the place of installation that is it is possible to set up the detector’s class and its operation ...
Page 4
4 IK‐E283‐002GB 3.3 Anti‐dusting eye protection It is obligatory to use protective anti‐dusting glasses and masks during detector installation works that produce high amount of dust, such as hole drilling in ceilings. 4 DESIGN DESCRIPTION The detector mechanical construction is shown on Fig. 1. Its basic element is a detecting module consisting of a temperature‐sensitive resistor (thermistor). The thermistor, protruding above the detector ...
Page 5
IK‐E283‐002GB 5 Communication between the POLON 4000 system fire alarm control panel and the TUN‐4043 detectors is provided using a two‐wire addressable detection line. A unique, fully digital communications protocol enables passing any information from the control panel to the detector and inversely. ...
Page 6
6 IK‐E283‐002GB lines with straight branches, or in radial detection lines of the POLON 4000 system (compare the POLON 4200 control panel manual). The detectors are installed in the 40 model range bases. A detection line connection method is presented in the G‐40 base installation and maintenance manual. An additional optical alarm signal of a detector or a group of detectors can be obtained by connecting the WZ‐31 alarm actuation indicator. ...
