- Page 1 IK-E354-001GB FIRE ALARM SYSTEM POLON 4000 INPUT/OUTPUT ELEMENT EKS-4001W Installation and Maintenance Manual IK-E354-001GB Issue IC...
- Page 2 Failure to follow the instructions included in this manual may be dangerous or result in the violation of applicable regulations. As the manufacturer, Polon-Alfa is not liable for any damages resulting from the improper device operation that is not in accordance with this manual.
- Page 3 IK-E354-001GB Polon-Alfa S.A. 85-861 Bydgoszcz, ul. Glinki 155 1438 1438/CPR/0399 EKS-4001WInput/Output element EN 54-18, EN 54-17 Declaration of Performance no. 1/E354/2013/PL Harmonised technical Product essential characteristic Performance specification EN 54-18:2005 Chapter Reaction delay Properties and resistance to Pass power supply parameter change...
- Page 4 IK-E354-001GB Harmonised technical Product essential characteristic Performance specification EN 54-18:2005 Chapter Durability and operation reliability: electrical stability Properties and resistance to Pass power supply parameter change Resistance to electromagnetic interference Pass 5.12 Harmonised technical specification Product essential characteristic Performance EN 54-17:2005 Chapter Efficiency in fire conditions Reproducibility...
- Page 5 IK-E354-001GB Table of contents Design ..........................6 Technical data........................7 Description of the design ....................8 Description of the operation ....................9 Operating mode of the I/O element ................. 11 Operating conditions ......................12 Installation of I/O elements ....................12 Safety conditions .......................
- Page 6 EKS-4001W I/O element is intended for use in addressable detection lines of POLON 4000 fire detection and alarm control panel. The element is designed to be operated indoors and outdoors.
- Page 7 IK-E354-001GB 2. Technical data Detection line supply voltage 16.5 – 24.6 V Current consumption from detection line < 250 µA Detection line short-circuit insulator Configuration of I/O element yes (jumpers on printed circuit board) Number of outputs Relay control output potential-free, supervised, change-over contact max.
- Page 8 IK-E354-001GB 3. Description of the design EKS-4001W I/O element is designed in the form of a printed circuit board with electronic components and a connector set, that has been put inside an enclosure. The enclosure has wall mounting holes in the corners. Cable glands are located in the enclosure body, along longer sides.
- Page 9 IK-E354-001GB 4. Description of the operation The communication between POLON 4000 control panel and EKS-4001W I/O element is carried out via an addressable two-wire detection line. Unique, fully digital communication protocol enables transferring any information from the control panel to the element and from the element to the control panel.
- Page 10 IK-E354-001GB b) Two jumpers: IN1-IN HV1 and IN2-IN HV2 are used for input selection. By default, jumpers in IN1, IN2 positions, two IN1, IN2 low-voltage inputs are selected: Example: 1. In order to use IN1 as a low-voltage input, you should: Set jumper to IN1 position.
- Page 11 IK-E354-001GB For example, if you decide to monitor the continuity of the cable connected to output 1, the jumper should be set in ON1 position, and the controlled device is powered with e.g. 230 VAC, the jumper should be set to HI1, which corresponds to a low state of about 75 V. When the controlled device is powered with e.g.
- Page 12 7. Installation of I/O elements It is recommended to install EKS-4001W I/O elements in a detection line near controlled devices. The elements can operate in detection lines of POLON 4000 control panels. (See Operation and Maintenance Manual of POLON 4000 control panel.) Connection method of EKS-4001W to IN inputs is shown in the drawing: Figure 3.
- Page 13 IK-E354-001GB Figure 2 Printed circuit board and terminal view of EKS-4001W...
- Page 14 IK-E354-001GB Detection line + – L1– ROP-4001 – – L2– SHLD SHLD EKS-4001W TUN-4046 – – OFF1 Controlled Power device supply 1A (NO1) – 24 VDC 1B (COM1) Detection – 1C (NC1) line/loop 2 kΩ 4.3 k IN1+ Ω IN1– Monitored device OFF3 2 kΩ...
- Page 15 IK-E354-001GB Detection line + – L1– ROP-4001 – – L2– SHLD SHLD EKS-4001W TUN-4046 – – OFF1 Controlled Power device supply 1A (NO1) – 230 VAC 1B (COM1) Detection – 1C (NC1) line/loop IN1+ IN1– OFF3 Power IN2+ supply 3A (IN HV1+) IN2–...
- Page 16 IK-E354-001GB Figure 5 Functions of EKS-4001W terminals...
- Page 17 Maintenance and periodic inspections must be carried out by personnel that is authorised or trained by Polon-Alfa. All repairs must be carried out by the manufacturer. Polon-Alfa is not responsible for the operation of the equipment maintained and repaired by unauthorized personnel. 8.2.
