- Page 1 PUO-40 AND PUO-40Ex ULTRAVIOLET FLAME DETECTORS _________________________________________________________________________________ INSTALLATION and MAINTENANCE MANUAL IK-E368-001GB 2 Edition...
- Page 2 IK-E368-001GB PUO-40 and PUO-40Ex flame detectors which are the subject of this manual, meets the essential requirements of the following European Parliament and Council (EU) regulations and European Union directives: CPR/305/2011 The European Parliament and the Council (EU) regulation of March 9, 2011 stipulating harmonized conditions for placing construction products on the market and repealing Council Directive 89/106/EEC;...
- Page 3 IK-E186-001GB Table of contents 1. PURPOSE………………………………………………………………………………………………………………………….4 2. TECHNICAL SPECIFICATIONS…………………………………………………………..…………………………………4 3. INTRINSIC SAFETY PARAMETERS……………………………………………………………………………………….4 4. USE CONDITIONS………………………………………………………………………………………………………………5 4.1 Repairs and maintenance……………………………………………………………………………………………….5 4.2 Work at heights………………………………………………………………………………………………………………5 4.3 Anti-dusting eye protection…………………………………………………………………………………………….6 5. CONSTRUCTION AND OPERATION PRINCIPLE……………………………………………………………………..6 6. OPERATING DESCRIPTION………………………………………………………………………………………….………6 7. MAINTENANCE AND REPAIRS…………………………………………………………………………………………..7 8.
- Page 4 IK-E368-001GB PURPOSE are designed for detection of flame resulting from a The PUO-40 and PUO-40Ex flame detectors fire hazard in zones where in normal conditions no flame related processes take place and no direct sunlight operates on the detector’s body.
- Page 5 Any maintenance works or periodic inspection shall be executed by skilled personnel employed by companies authorised and trained by POLON-ALFA. Any repairs must be carried out by the manufacturer. POLON-ALFA bears no responsibility for the operation of any apparatus being repaired by unauthorised personnel. 4.2 Works at height Any detector installation works carried out at height must be executed with particular care utilising tools and machinery in good working condition.
- Page 6 The actuation test may be carried out using a lighter or match flame. PUO-40 detectors should be installed in such a manner that eliminates direct sunlight to fall directly on the sensor.
- Page 7 DETECTORS INSTALLATION PUO-40/40Ex detectors are installed according to selected design guidelines in ‘40’ model range bases. The detection line connection is shown in Fig. 3 and in the G-40 base installation and maintenance manual. Additional optical signalling of a single detector or a group of detectors can be obtained by connecting the WZ-31 alarm indicator.
- Page 8 IK-E368-001GB STORAGE AND TRANSPORTATION The PUO-40 and PUO-40Ex detectors must be kept in individual packages in closed rooms free of acid or alkaline vapours and volatile compounds of sulphur at the temperature between -10 °C and +55 °C and relative humidity up to 80 %.
- Page 9 IK-E186-001GB...
